Sharp 10.4 Inch Industrial LCD Display with 350 cd/m² Brightness and 800×600 Pixels Resolution

Name: Sharp 10.4 Inch Industrial LCD Display with 350 cd/m² Brightness and 800×600 Pixels Resolution
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LQ104S1DG21
Price: 43.00 USD
Availability: InStock

Brand Name:	sharp
Model Number:	LQ104S1DG21
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

Japan

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

262k Colors

Model:

WLED

Style:

Wide Screen High Resolution 640*1480

Brightness:

350cd

Connector:

31pin

Contrast Ratio:

300:1

Working Life:

50K Hours

Packaging Details:

Industrial packing

Highlight:

industrial panel pc touch screen

industrial computer monitor

Product Description

Sharp 10.4 Inch Industrial Panel PC Touch Screen

Product Overview

High brightness LQ104S1DG21 display panel with 800*600 SVGA resolution, designed for industrial applications requiring reliable performance in demanding environments.

Technical Specifications

Manufacturer	Sharp	Model Name	LQ104S1DG21
Screen Size	10.4 inch	Screen Type	LCM, a-Si TFT-LCD
Resolution	800*600 pixels (SVGA)	Pixel Arrangement	RGB Vertical Stripe
Active Area	211.2 * 158.4 mm	Outline Dimensions	246.5 * 179.4 mm
Bezel Area	214.6 * 162.4 mm	Surface Treatment	Antiglare, Hard coating (3H), Antireflection
Luminance	350 cd/m² (Typical)	Contrast Ratio	300:1 (Typical)
Viewing Angle	70/70/40/70 (CR≥10)	Response Time	10/25 ms (Tr/Td)
Optimal View	6 o'clock	Operation Mode	TN, Normally White, Transmissive
Color Depth	262K colors	Backlight System	2 CCFL lamps, 50K hours lifespan
Weight	620g (Maximum)	Touchscreen	Without touch capability
Signal Type	CMOS (1 channel, 6-bit)	Connector	41 pins
Voltage Supply	3.3V/5.0V (VCC)	Operating Temperature	-10°C to 65°C
Storage Temperature	-30°C to 70°C	Max Vibration	1.0G (9.8 m/s²)

Key Features

Antiglare surface treatment for reduced reflections
Landscape orientation configuration
Replaceable CCFL backlight lamps
Extended backlight lifespan ≥ 50,000 hours
U/D, L/R reverse functionality
Industrial-grade construction for harsh environments

Product Status Information

This model entered mass production in Q2 2003 with final shipments completed in Q3 2011. The product is now discontinued.

Important Notice: This model is no longer in production. For current product specifications and availability, we strongly recommend contacting Sharp or their authorized agents directly.

Quality Assurance: All our LCD/LED screen monitor module panel products undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.
