AUO Industrial LCD Display 17.3 inch 400cd/m2 Brightness 30 Pin Connector Touch Screen Panel

Name: AUO Industrial LCD Display 17.3 inch 400cd/m2 Brightness 30 Pin Connector Touch Screen Panel
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: G173HW01 V0
Price: 43.00 USD
Availability: InStock

Brand Name:	AUO
Model Number:	G173HW01 V0
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1080

Brightness:

400cd

Connector:

30pin

Contrast Ratio:

600:1

Working Life:

50K Hours

Packaging Details:

Industrial packing

Highlight:

industrial panel pc touch screen

industrial computer monitor

Product Description

AUO Industrial Panel LCD Touch Screen Panel 17.3" 400cd/m² Brightness G173HW01 V0 30 Pin

Technical Specifications

Manufacturer AUO

Model G173HW01 V0

Screen Size 17.3 inch

Screen Type LCM, a-Si TFT-LCD

Resolution 1920*1080 (FHD)

Brightness 400 cd/m²

Contrast Ratio 600:1

Viewing Angle 80/80/60/80 (CR≥10)

Response Time 37/3 ms (Tr/Td)

Color Depth 16.7M colors, 72% CIE1931

Backlight WLED, 50K hours

Signal Interface LVDS (2 ch, 8-bit), 30 pins

Operating Voltage 3.3V

Operating Temperature 0°C to 70°C

Storage Temperature -30°C to 75°C

Weight 1.08 kg

Key Features

High brightness 400cd/m² for industrial applications
Full HD 1920*1080 resolution
WLED backlight with 50,000 hours lifespan
Wide viewing angle performance
Glare surface with 3H hard coating
Landscape orientation design
Replaceable backlight lamps
LVDS signal interface with 30-pin connector
Rugged construction for industrial environments

Product Overview

The G173HW01 V0 is a 17.3-inch diagonal a-Si TFT-LCD display panel from AU Optronics Corp., featuring an integrated WLED backlight system with LED driver. This industrial-grade panel operates within a temperature range of 0°C to 70°C and can withstand storage temperatures from -30°C to 75°C, with maximum vibration tolerance of 1.5G (14.7 m/s²).

This 400cd/m² LCD model is specifically designed for industrial field use. All our LCD LED screen monitor module panel products undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.

Note: Production status information is for reference only and should not be used as the basis for decision-making. We strongly recommend contacting AUO or their authorized agents for the latest production and specification details of the G173HW01 V0 model.
