| Brand Name: | INNOLUX |
| Model Number: | G121XCE-L01 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Brand | Innolux | Model | G121XCE-L01 |
|---|---|---|---|
| Diagonal Size | 12.1 inch | Type | a-Si TFT-LCD , LCM |
| Pixel Format | 1024(RGB)×768 [XGA] | Configuration | RGB Vertical Stripe |
| Active Area | 245.76(H)×184.32(V) mm | Outline Dim. | 260.5(H)×204(V) ×8.9(D) mm |
| Bezel Area | 249.0(H)×187.5(V) mm | Treatment | Antiglare, Hard coating (3H) |
| Luminance | 600 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 13/12 (Typ.)(Tr/Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | AAS, Normally Black, Transmissive |
| Support Color | 262K/16.2M 72% (CIE1931) | Light Source | WLED , 50K hours , With LED Driver |
| Weight | 490/510g (Typ./Max.) | Designed For |
|
| Frame Rate | 60Hz | Touch Panel | Without |
| Interface Type | 20 pins LVDS (1 ch, 6/8-bit) , Connector | ||
| Power Supply | 3.3V (Typ.) | ||
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C | ||
It's 600cd/m2 lcd MODEL for industrial lcd ,computer,all-in-one computer,desktop,laptop lcd.
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
