AUO 19" Industrial LCD Display Model Medical Imaging Screen 280*1024 Pixels G190EG02 V0 1

Brand Name:	AUO
Model Number:	G190EG02 V0
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

Style:

Wide Screen High Resolution 1280*1024

Brightness:

600cd

Connector:

30pin

Contrast Ratio:

2000:1

Working Life:

50K Hours

Supply Ability:

3000pcs per week

Highlight:

industrial panel pc touch screen

industrial computer monitor

Product Description

anel Brand
AUO
Panel Model
G190EG02 V0

Panel Size
19.0"
Panel Type
a-Si TFT-LCD, LCM

Resolution
1280(RGB)×1024 , SXGA
Pixel Format
RGB Vertical Stripe

Display Area
376.32(W)×301.056(H) mm
Bezel Opening
380.32(W)×305.06(H) mm

Outline Size
396(W)×324(H) ×21.85(D) mm
Surface
Antiglare, Hard coating (3H)

Brightness
600 cd/m² (Typ.)
Contrast Ratio
2000:1 (Typ.) (TM)

Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
MVA, Normally Black, Transmissive

Best View on
Symmetry
Response Time
15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G)

Display Colors
16.7M 70% (CIE1931)
Lamp Type
WLED , 50K hours , With LED Driver

Frequency
60Hz
Touch Screen
Without

Panel Weight
2.00/2.10Kgs (Typ./Max.)
Application

Signal Interface
LVDS (2 ch, 8-bit) , 30 pins , Connector

Input Voltage
5.0V (Typ.)

Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

It's 600cd/m2 high brightness industrial lcd Original package of AUO lcd panel.

All our LCD LED screen monitor module panel products will be full test one by one before sending .
