CMO 21.3" Medical Imaging Industrial LCD Display R213T1-L01 2560*2048 Pixels 1000cd/m2

All Category

Widescreen LCD Computer Monitors

Medical LCD Panel

Mr. pippo tian

pippo@ridafone.com

+86 13590447319

Contact Now

CMO 21.3" Medical Imaging Industrial LCD Display R213T1-L01 2560*2048 Pixels 1000cd/m2

Brand Name:	CMO
Model Number:	R213T1-L01
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

japan

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

262 Colors

Model:

Style:

Wide Screen High Resolution 2560*2048

Brightness:

1000cd

Connector:

73pin

Contrast Ratio:

700:1

Working Time:

50k Hours

Supply Ability:

3000pcs per week

Highlight:

industrial computer monitor

industrial touch screen display

Product Description

Brand
Diagonal Size
Pixel Format
Active Area
Bezel Area
Luminance
View Direction
Viewing Angle
Support Color
Weight
Frame Rate

CMO

21.3 inch

2560(LCR)×2048 [QSXGA]

422.4(H)×337.92(V) mm

426.4(H)×344.5(V) mm

1000 cd/m² (Typ.)

Symmetry

85/85/85/85 (Typ.)(CR≥10)

Grayscale

2.97Kgs (Typ.)

60Hz

Model

Type

Configuration

Outline Dim.

Treatment

Contrast Ratio

Response Time

Operating Mode

Light Source

Designed For

Touch Panel

R213T1-L01

a-Si TFT-LCD , LCM

LCR Vertical Stripe

459.8(H)×375.3(V) ×49(D) mm

700:1 (Typ.) (TM)

25/25 (Typ.)(Tr/Td)

DD-IPS, Normally Black, Transmissive

CCFL [12 pcs] , 50K hours , With Inverter

Without

Interface Type	73 pins LVDS (4 ch, 8-bit) , Connector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

All our LCD LED screen monitor module panel products will be full test one by one before sending .
