DV215FHM-NN0 21.5 Inch Industrial Panel PC with 1920x1080 Resolution and 500cd Brightness for Vending Machines

Name: DV215FHM-NN0 21.5 Inch Industrial Panel PC with 1920x1080 Resolution and 500cd Brightness for Vending Machines
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: DV215FHM-NN0
Price: 43.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	DV215FHM-NN0
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

KOREA

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1080

Brightness:

500cd

Connector:

30pin

Contrast Ratio:

1000:1

Packaging Details:

Industrial packing

Highlight:

industrial computer monitor

industrial touch screen display

Product Description

DV215FHM-NN0 Industrial Panel PC Touch Screen

Product Overview

21.5-inch industrial-grade panel PC display designed specifically for vending machine applications, featuring BOE's advanced TFT-LCD technology.

Manufacturer Specifications

Manufacturer: BOE

Model: DV215FHM-NN0

Screen Size: 21.5 inch

Screen Type: LCM, a-Si TFT-LCD

Resolution: 1920*1080 (FHD)

Pixel Arrangement: RGB Vertical Stripe

Physical Dimensions

Active Area: 476.064 * 267.786 mm (H*V)

Outline Dimensions: 495.6 * 292.2 mm (H*V*D)

Bezel Area: 479.8 * 271.2 mm (H*V)

Weight: 1.97 kg (Typical)

Display Performance

Specification	Value
Luminance	500 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	89/89/89/89 (CR≥10)
Response Time	14 ms (G to G, Typical)
Refresh Rate	75Hz
Color Depth	16.7M colors, 73% (CIE1931)

Technical Features

Surface Treatment: Antiglare with Hard coating (3H)
Viewing Mode: Symmetry
Work Mode: ADS, Normally Black, Transmissive
Backlight: 3 strings WLED, 30K hours lifespan, No Driver required
Touchscreen: Without touch capability
Signal Type: LVDS (2 ch, 8-bit), 30-pin connector
Voltage Supply: 5.0V (Typical)

Environmental Specifications

Operating Temperature: 0°C to 50°C

Storage Temperature: -20°C to 60°C

Application

Specifically designed for vending machine systems and industrial panel PC applications requiring reliable, high-visibility displays.

Quality Assurance: All our LCD/LED screen monitor module panel products undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.
