Hannstar 10.3 inch Car LCD Display HSD103KPW2-A10 with 1920*720 Pixels and 850 cd/m² Brightness for Automotive Applications

Name: Hannstar 10.3 inch Car LCD Display HSD103KPW2-A10 with 1920*720 Pixels and 850 cd/m² Brightness for Automotive Applications
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: HSD103KPW2-A10
Price: 30.00 USD
Availability: InStock

Brand Name:	Hannstar
Model Number:	HSD103KPW2-A10
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1920*720pixels

Style:

WLED 50P

Brightness:

850CCD M2

Color:

16.7M

Contrast Ratio:

1000 :1

Working Life:

20K Hours

Packaging Details:

Industrial packing

Highlight:

tft lcd display

raspberry pi 7 touchscreen display

Product Description

Hannstar 10.3-inch High Brightness Car LCD Display HSD103KPW2-A10

High-performance 10.3-inch automotive LCD display panel with 1920*720 resolution, 850 cd/m² brightness, and extended 20,000-hour working life. Designed for demanding automotive applications with wide temperature operation and vibration resistance.

Product Specifications

Brand & Model	HannStar HSD103KPW2-A10
Display Size	10.3 inch diagonal
Display Type	a-Si TFT-LCD, IPS Pro Technology
Resolution	1920(RGB)*720 pixels
Active Area	243.648 * 91.368 mm
Brightness	850 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	85/85/85/85 (CR≥10)
Response Time	35ms (Max.)
Backlight	50P WLED, 20K hours lifespan
Interface	50 pins LVDS (2 ch, 8-bit)
Power Supply	3.3V (Typical)
Operating Temperature	-30°C to 85°C
Vibration Resistance	2.9G (28.4 m/s²)
Weight	360g (Typical)

Key Features

High brightness 850 cd/m² for excellent outdoor visibility
Wide temperature operation (-30°C to 85°C)
3G vibration resistance for automotive durability
IPS Pro technology with wide viewing angles
20,000-hour WLED backlight lifespan
Anti-glare hard coating (3H) surface treatment
Bar display format optimized for automotive applications

Application Recommendations: This high-brightness display is specifically designed for outdoor automotive applications including car GPS displays, infotainment systems, and other vehicle display interfaces requiring superior visibility and durability.

Quality Assurance: All products undergo individual inspection before shipment and include one-year comprehensive warranty service.
