LG 43inch LCD Display Screen with 700CD Brightness 3840*2160pixels Resolution and 51PIN Connector for Digital Signage

Name: LG 43inch LCD Display Screen with 700CD Brightness 3840*2160pixels Resolution and 51PIN Connector for Digital Signage
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LD430EQE-FSA1
Price: 30.00 USD
Availability: InStock

Brand Name:	LG
Model Number:	LD430EQE-FSA1
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Brightnerss:

700CCD/M2

Connector:

51P

Color:

1.07B

Contrast Ratio:

1000:1

Working Life:

30K Hours

Touch Panel:

Without

Resolution:

3640*2160pixels

Packaging Details:

Industrial packing

Highlight:

700CD Brightness LCD Display Screen

3840*2160pixels Resolution LCD Panel

51PIN Connector Digital Signage Display

Product Description

LG 43-inch LCD Display Screen LD430EQE-FSA1

High-brightness 43-inch UHD LCD panel designed for outdoor digital signage applications. Features 3840×2160 resolution, 700 cd/m² brightness, and IPS technology for wide viewing angles.

Note: This model has been discontinued. Contact LG Display or their agent for latest production and specification details.

Product Overview

The LD430EQE-FSA1 is a 43-inch diagonal a-Si TFT-LCD display panel from LG Display featuring an integral WLED backlight system. This high-brightness panel is engineered for demanding outdoor digital signage applications with excellent visibility in various lighting conditions.

Technical Specifications

Model Number: LD430EQE-FSA1

Diagonal Size: 43 inches

Resolution: 3840×2160 (UHD), 103 PPI

Brightness: 700 cd/m² (Typical)

Contrast Ratio: 1000:1 (Typical)

Panel Type: a-Si TFT-LCD, IPS Technology

Viewing Angle: 89°/89°/89°/89° (L/R/U/D)

Response Time: 6ms (G to G)

Display Colors: 1.07 Billion, 72% NTSC

Active Area: 941.184×529.416 mm

Outline Dimensions: 962×554.8×34.6 mm

Weight: 8.3 kg (Typical) / 8.7 kg (Maximum)

Backlight: WLED, 30,000 hours lifespan

Interface: V-by-One 8 lane, 51-pin connector

Input Voltage: 12.0V DC (Typical)

Operating Temperature: 0°C to 50°C

Storage Temperature: -20°C to 60°C

Surface Treatment: Antiglare (Haze 28%), Hard coating (2H)

Application

Specifically designed for Digital Signage and Outdoor High Brightness applications where superior visibility and reliability are essential.

Important: Production status information is for reference only and should not be used as the sole basis for decision-making. Always verify current specifications with LG Display or authorized representatives.
