BOE 49inch LCD Display Panel HV490FHB-N80 with 1920*1080pixels Resolution 51pin Connector and 500cd Brightness

Name: BOE 49inch LCD Display Panel HV490FHB-N80 with 1920*1080pixels Resolution 51pin Connector and 500cd Brightness
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: HV490FHB-N80
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	HV490FHB-N80
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m

Model:

Lcm

Style:

Wide Screen High Resolution 1920*1080PIXELS

Brightness:

500cd

Connector:

51PIN

Contrast Ratio:

1200:1

Working Time:

50k Hours

Input Voltage:

12V

Signal Type:

LVDS

Packaging Details:

Industrial packing

Highlight:

51pin Lcd Display

HV490FHB-N80 Lcd Display

BOE 49inch Lcd Display

Product Description

BOE 49-inch LCD Display Panel HV490FHB-N80

BOE Technology Group Co., Ltd. HV490FHB-N80 is a 49-inch diagonal a-Si TFT-LCD display panel designed for professional applications. This high-resolution panel features 1920×1080 pixels and is engineered for TV sets and digital signage applications.

Key Features

49-inch diagonal display with 1920×1080 FHD resolution
a-Si TFT-LCD panel technology without backlight or touch screen
Matte surface with narrow bezel design
Built-in 6 source chips driver IC
LVDS interface with 51-pin connector
Suitable for TV sets and digital signage applications

Technical Specifications

Brand	BOE
Model Number	HV490FHB-N80
Panel Size	49-inch diagonal
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	1920(RGB)×1080 (FHD), 45 PPI
Active Area	1073.78mm (W) × 604mm (H)
Viewing Angle	89/89/89/89 (CR≥10) Left/Right/Up/Down
Contrast Ratio	1200:1 (Typical)
Response Time	8ms (Typical, G to G)
Color Support	16.7M colors, 73% NTSC
Frame Rate	60Hz standard, 120Hz with embedded MEMC circuit, 240Hz with MEMC
Operating Mode	ADS, Normally Black, Transmissive (IPS Family)
Interface	LVDS (2 ch, 8-bit), 51-pin connector
Power Supply	12.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Weight	1.97kg (Typical)

Product Images

Note: Production status information is for reference only. For the latest production and specification details, please contact BOE or their authorized distributors before making purchasing decisions.
