Innolux 58Inch Large LCD Display Screen S580DJ2-KS5 3840*2160pixels 76PPI 1.07 Billion Colours 56P

Innolux 58Inch Large LCD Display Screen S580DJ2-KS5 3840*2160pixels 76PPI 1.07 Billion Colours 56P

S580DJ2-KS5 is a 58" diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -15 ~ 60°C . It's general features are summarized by Einklcd in the following: DCI-P3, sRGB, 120Hz, WLED Backlight, With LED Driver, Reverse I/F, 10 bit, Matte . Based on its features, Einklcd recommend that this model be applied to Digital Signage etc. According to the information stored in einklcd this model mass production on Q2, 2016, Now this model is discontinued. We inputted this model's specification on Nov 17 2017 for the first time, and the latest update on Oct 15 2023. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with Innolux or it's agent to learn lateast production and specification detail of S580DJ2-KS5. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand

Innolux

Model

S580DJ2-KS5

Diagonal Size

58 inch

Type

a-Si TFT-LCD, LCM

Pixel Format

3840(RGB)×2160 [UHD]

Configuration

RGB Vertical Stripe

Active Area

1270.08(W)×721.44(H) mm

Outline Dim.

1290.3(H)×744.7(V) ×29.4(D) mm

Bezel Area

1275.3(W)×726.7(H) mm

Treatment

Antiglare (Haze 1%)

Luminance

500 cd/m² (Typ.)

Contrast Ratio

4000:1 (Typ.) (TM)

View Direction

Symmetry

Response Time

9.5 (Typ.)(G to G)

Viewing Angle

89/89/89/89 (Typ.)(CR≥10)

Operating Mode

Super MVA, Normally Black, Transmissive

Support Color

1.07B

Light Source

WLED , 30K hours , With LED Driver

Weight

16.4/17.3/18.1Kgs (Min./Typ./Max.)

Designed For Digital Signage

Frame Rate

120Hz

Touch Panel

Without

Interface Type

56pins V-by-One 8 lane , Connector

Power Supply

12.0V (Typ.)

Environment

Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

•
• All Origianl product will be send to customer after full test one by one.

• Spec details can be send to you via email,please contact us.
