Innolux 58-Inch Large LCD Display Screen S580DJ2-KS5
The S580DJ2-KS5 is a 58-inch diagonal a-Si TFT-LCD display panel from Innolux Corporation, featuring UHD resolution (3840×2160 pixels), 76 PPI, and 1.07 billion colors. This professional-grade display module includes an integral WLED backlight system with LED driver and is designed without a touch screen.
Key Specifications
Display Technology
a-Si TFT-LCD, Super MVA
Resolution
3840(RGB) × 2160 (UHD)
Pixel Configuration
RGB Vertical Stripe
Active Area
1270.08 × 721.44 mm
Brightness
500 cd/m² (Typical)
Contrast Ratio
4000:1 (Typical)
Response Time
9.5 ms (G to G, Typical)
Refresh Rate
120Hz
Color Support
1.07 Billion Colors (10-bit)
Viewing Angle
89/89/89/89 (CR ≥10)
Backlight
WLED, 30,000 hours lifespan
Interface
56-pin V-by-One 8 lane connector
Power Supply
12.0V (Typical)
Operating Temperature
0°C to 50°C
Storage Temperature
-20°C to 60°C
Weight
16.4/17.3/18.1 kg (Min/Typ/Max)
Product Features
This display panel supports DCI-P3 and sRGB color gamuts and features a matte anti-glare surface treatment (1% haze) for reduced reflections. The normally black, transmissive operating mode provides excellent image quality for professional applications.
Application
Designed specifically for digital signage applications, this high-performance display offers exceptional color reproduction, wide viewing angles, and reliable operation in commercial environments.
Important Information
All original products undergo comprehensive testing before shipment
Detailed specifications available via email upon request
Product originally entered mass production in Q2 2016 (now discontinued)
Contact Innolux or authorized agents for latest production status and specifications
