7Inch Innolux Car LCD Display NJ070NA-23A with 500 cd/m² Brightness 1024×600 Pixels and 40 Pin Connector

Name: 7Inch Innolux Car LCD Display NJ070NA-23A with 500 cd/m² Brightness 1024×600 Pixels and 40 Pin Connector
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: NJ070NA-23A
Price: 30.00 USD
Availability: InStock

Brand Name:	innolux
Model Number:	NJ070NA-23A
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

500ccd/m2

Resolution:

1024*600pixels

Contrast Ratio:

800:1

Color:

16.7M

Working Life:

20k Hours

Connector:

40P

Touch Panel:

Without

Working Voltage:

3.3v

Packaging Details:

Industrial packing

Highlight:

1024*600Pixels Car LCD Display

7Inch innolux Car LCD Display

NJ070NA-23A Car LCD Display

Product Description

7-Inch Innolux Car LCD Display NJ070NA-23A

High-Brightness 7-Inch Automotive TFT-LCD Display featuring 500 cd/m² luminance, 1024*600 resolution, and 170 PPI pixel density. Designed specifically for automotive applications with robust environmental specifications.

Product Overview

The NJ070NA-23A is a 7.0-inch diagonal a-Si TFT-LCD display panel from Innolux Corporation, featuring an integrated WLED backlight system. This automotive-grade display operates within a wide temperature range of -20°C to 70°C and withstands vibration levels up to 1.5G (14.7 m/s²).

Production Status: Currently in production (initial mass production Q2 2017). Contact Innolux or their authorized agents for the latest production and specification details.

Technical Specifications

Brand	Innolux
Model Number	NJ070NA-23A
Diagonal Size	7.0 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	1024(RGB)*600 (WSVGA), 170 PPI
Active Area	154.214 * 85.92 mm
Luminance	500 cd/m² (Typical)
Contrast Ratio	800:1 (Typical)
Viewing Angle	80/80/60/70 (Left/Right/Up/Down, CR≥10)
Response Time	10/15 ms (Typical, Tr/Td)
Interface	LVDS (1 channel, 6/8-bit), 40-pin FPC
Power Supply	3.3/12/15/-10V (DVDD/AVDD/VGH/VGL)
Operating Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C
Weight	1350g (Typical)
Touch Panel	Without touch screen

Key Features

• WLED backlight system with 20,000-hour lifespan
• U/D, L/R reverse functionality
• 6/8-bit color support
• Hard coating treatment for durability
• Built-in EK79001AX + EK73215BCGA driver IC
• TN technology with normally white, transmissive operation
• Supports 262K/16.7M colors
• 60Hz frame rate

Product Images

Application

Specifically designed for automotive display applications requiring high brightness, wide temperature operation, and vibration resistance. Ideal for in-vehicle infotainment systems, instrument clusters, and other automotive display requirements.
