AUO 10Inch Industrial Lcd Panel Automotive Lcd Screen C100HAT01.2 1560X700P 171PPI 1000CD/M2 60PIN

Brand Name:	Ortustech
Model Number:	C100HAT01.2
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1560*700pixels

Style:

60PIN IPS

Brightness:

1000CD/M2

Color:

16.7M

Contrast Ratio:

600 :1

Working Life:

70K Hours

Type:

Size:

10inch

Lamp Type:

Voltage:

Supply Ability:

3000pcs per week

Highlight:

C100HAT01.2 automotive lcd screen

1560X700P industrial lcd panel

AUO 10Inch industrial lcd panel

Product Description

AUO 10Inch industrial lcd panel automotive lcd screen C100HAT01.2 1560X700P 171PPI 1000CD/M2 60PIN

AU Optronics Corp. (hereafter called AUO) C100HAT01.0 is a 10.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -40 ~ 95°C . It's general features are summarized by einklcd in the following: Wide Temperature, WLED Backlight, U/D,L/R Reverse, Matte . Based on its features, einklcd recommend that this model be applied to Automotive Display etc. According to the information stored in einklcd this model mass production on Q3, 2019 and last shippment on Q1, 2022, Now this model is discontinued. We inputted this model's specification on May 29 2020 for the first time, and the latest update on Mar 3 2021. If you want to embed C100HAT01.0 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The C100HAT01.0 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand: AUO

Model P/N: C100HAT01.0

Diagonal Size:10.0"

Panel Type: a-Si TFT-LCD, LCM

Resolution: 1560(RGB)×700 171PPI Pixel

Format: RGB

Vertical Stripe

Active Area: 231.66(W)×103.95(H) mm

Bezel Opening-

Outline Size :259.36(W)×131.32(H) mm

Surface Antiglare, Antire flection

Viewing Angle :80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down Display Mode AHVA, Normally Black, Transmissive.

IPS Family: AAS, ADS, AHVA, FFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Best View on Symmetry Response Time 30 (Max.)(Tr+Td)

Display Colors 16.7M Lamp Type WLED

Frequency 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit Touch Screen -

Panel Weight 375±38g Application Automotive Display

Signal Interface LVDS (2 ch, 8-bit) , 60 pins Connector

Environment Operating Temp.: -30 ~ 85 °C ;

Storage Temp.: -40 ~ 95 °C
