| Brand Name: | innolux |
| Model Number: | DJ103IA-03B |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Innolux 10.3inch Automotive LCD Display High Brightness 800 cd/m² 1920*720Pixels DJ103IA-03B 50pin 3.3V
Innolux Corporation (hereafter called Innolux) DJ103IA-03B is a 10.3 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -40 ~ 90°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: sRGB, Wide Temperature, Hight Brightness, WLED Backlight, Bar Display, U/D,L/R Reverse, Matte . Based on its features, einklcd recommend that this model be applied to Automotive Display etc. According to the information stored in einklcd this model mass production on Q2, 2016, Now this model is discontinued. We inputted this model's specification on Jul 15 2016 for the first time, and the latest update on Jun 25 2021. If you want to embed DJ103IA-03B LCM in your future product, einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The DJ103IA-03B production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
| Outline Dim. | 259.84(H)×109.3(V) ×16(D) mm | Treatment | Antiglare |
|---|---|---|---|
| Luminance | 800 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 15/10 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Operating Mode | AAS, Normally Black, Transmissive |
| Support Color | 16.7M 85% NTSC | Light Source | WLED , 20K hours , W/O Driver |
| Weight | 380g (Max.) | Designed For | |
| Frame Rate | 60Hz | Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 50 pins Connector | ||
| Power Supply | 3.3V (Typ.) | ||
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C | ||
|
|
