Industrial AUO 13.3 Inch LCD Panel G133HAN01.1 1920X1080P 166PPI 400cd/M2 30PIN

AUO 13.3Inch Industrial LCD Display G133HAN01.1 1920X1080Pixels 166PPI 400cd/M2 30PIN

G133HAN01.1 is a 13.3" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -20 ~ 70°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Einklcd in the following: Wide Color Gamut, DCI-P3, sRGB, WLED Backlight, Life ≥ 50K hours, With LED Driver, Matte , One-Chip Solustion, JEIDA LVDS. Based on its features, Einklcd recommend that this model be applied to Industrial, Medical Imaging, Gaming etc. According to the information stored in Einklcd this model mass production on Q3, 2019, Now this model is in production. We inputted this model's specification on Sep 25 2020 for the first time, and the latest update on Nov 17 2022. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of G133HAN01.1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand
AUO
Model P/N
G133HAN01.1

Diagonal Size
13.3"
Panel Type
a-Si TFT-LCD, LCM

Resolution
1920(RGB)×1080, FHD 166PPI
Pixel Format
RGB Vertical Stripe

Active Area
293.472(W)×165.078(H) mm
Bezel Opening
295.07(W)×166.68(H) mm

Outline Dim.
309.7(W)×184.1(H)×10.1(D) mm
Treatment
Antiglare

Luminance
400 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (TM)

View Direction
Symmetry
Response Time
25 (Typ.)(Tr+Td)

Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
AHVA, Normally Black, Transmissive

Support Color
16.7M 90% NTSC
Light Source
WLED , 50K hours , With LED Driver

Weight
500g (Max.)
Designed For

Frame Rate
60Hz
Touch Panel
Without

Interface Type
LVDS (2 ch, 8-bit) , 30 pins Connector

Power Supply
3.3V (Typ.)

Environment
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C
