Product Details:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Resolution: | 1920*1080pixels | Style: | 30PIN IPS |
| Brightness: | 250CD/M2 | Color: | 16.7m |
| Contrast Ratio: | 1000 :1 | Working Life: | 30K Hours |
| High Light: | Medical Imaging Industrial LCD Display,LM215WF3-SLC1 Industrial LCD Display,250cd/M2 Desktop LCD Monitor |
||
LG 21.5Inch Industrial LCD Display Desktop Monitor Medical imaging lcd lm215wf3-slc1 1920*1080pixels 102PPI 250cd 30PIN
The LM215WF3-SLC1 (Alias: LM215WF3 (SL)(C1)) is a 21.5 inch diagonal a-Si TFT-LCD display panel product from LG Display Co., Ltd. (hereafter called LG Display), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: WLED Backlight, Upside I/F, Matte . Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Industrial, Medical Imaging etc. According to the information stored in einklcd this model mass production on Q3, 2010 and last shippment on Q3, 2022, Now this model is discontinued. We inputted this model's specification on Mar 17 2013 for the first time, and the latest update on Aug 30 2021. If you want to embed LM215WF3-SLC1 LCM in your future product, Einklcd strongly recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail. The LM215WF3-SLC1 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
Panel Brand
LG
Display Panel Model
LM215WF3-SLC1
Panel Size
21.5" Panel
Type a-Si TFT-LCD , LCM
Resolution
1920(RGB)×1080, FHD, 102PPI Pixel
Format
RGB Vertical Stripe
Display Area
475.2(W)×267.3(H) mm
Bezel Opening
478.8(W)×271.3(H) mm
Outline Size
495.6(W)×292.2(H) ×10.7(D) mm
Surface Antiglare, Hard coating (3H)
Brightness
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
IPS, Normally Black, Transmissive
Best View on Symmetry Response Time 14 (Typ.)(G to G)
Display Colors 16.7M 72% NTSC
Lamp Type 13S4P WLED , 30K hours , Without Driver
Frequency 60Hz
Touch Screen Without
Panel Weight 1.19/1.25Kgs (Typ./Max.)
Application
Signal Interface
LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage
5.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
