350cd/M2 Large LCD Display Screen 76PPI Innolux 58" WLED V580DJ2-KS5

We visited their factory many times.Their workshop is very big and e ink display module are really great!

—— Chris

Our company have placed orders to Ridafone many times.They develop and produce all e ink LCD display items in good quality.

—— Picado Freddy

I'm Online Chat Now

350cd/M2 Large LCD Display Screen 76PPI Innolux 58" WLED V580DJ2-KS5

350cd/M2 Large LCD Display Screen 76PPI Innolux 58" WLED V580DJ2-KS5
350cd/M2 Large LCD Display Screen 76PPI Innolux 58" WLED V580DJ2-KS5 350cd/M2 Large LCD Display Screen 76PPI Innolux 58" WLED V580DJ2-KS5

Large Image :  350cd/M2 Large LCD Display Screen 76PPI Innolux 58" WLED V580DJ2-KS5

Product Details:
Place of Origin: China
Brand Name: innolux
Certification: Rohs,CE,FCC
Model Number: V580DJ2-KS5
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week
Detailed Product Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 1.07B Colors
Model: WLED Style: Wide Screen High Resolution 3840*2160PIXELS
Brightness: 350cd Connector: 51PIN
Contrast Ratio: 4000:1 Working Time: 30k Hours
Input Voltage: 12V Signal Type: V-by-one 8 Lane
High Light:

350cd/M2 Large LCD Display Screen

,

76PPI Large LCD Display Screen

,

FCC WLED Lcd Touch Display

Innolux 58" 3840×2160 350cd/M2 TV lcd mode V580DJ2-KS5







Innolux Corporation (hereafter called Innolux) V580DJ2-KS5 is a 58 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: 120Hz, 3D Display, WLED Backlight, With LED Driver, Reverse I/F, 10 bit, Matte , Surface Luminance, white 3D: 50 cd/m². Based on its features, einklcd recommend that this model be applied to TV Sets etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is discontinued.. We inputted this model's specification on Sep 6 2017 for the first time, and the latest update on Dec 11 2019. If you want to embed V580DJ2-KS5 LCM in your future product, Panelook strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The V580DJ2-KS5 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.







350cd/M2 Large LCD Display Screen 76PPI Innolux 58" WLED V580DJ2-KS5 0
