10.1" AUO Industrial Lcd Screen RGB Vertical 92PPI 60 Pin 300cd/M2 A101VW01 V3

AUO 10.1inch industrial lcd display panel 60pin 300cd/m2 A101VW01 V3

A101VW01 V3 (Alias: A101VW01 V.3) is a 10.1" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -10 ~ 60°C , a storage temperature range of -20 ~ 70°C . It's general features are summarized by einklcd in the following: WLED Backlight, U/D,L/R Reverse, Matte . Based on its features, einklcd recommend that this model be applied to Industrial, Digital Photo Frame, Portable DVD Player etc. According to the information stored in Einklcd this model mass production on Q3, 2009, Now this model is in production. We inputted this model's specification on Sep 22 2012 for the first time, and the latest update on May 7 2020. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of A101VW01 V3. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand

AUO

Model

A101VW01 V3

Diagonal Size

10.1 inch

Type

a-Si TFT-LCD, LCM

Pixel Format

800(RGB)×480 [WVGA] 92PPI

Configuration

RGB Vertical Stripe

Active Area

219.6(H)×131.76(V) mm

Outline Dim.

235(H)×145.9(V) mm

Bezel Area

221.6(H)×133.76(V) mm

Treatment

Antiglare

Luminance

300 cd/m² (Typ.)

Contrast Ratio

500:1 (Typ.) (TM)

View Direction

6 o'clock

Response Time

12/18 (Typ.)(Tr/Td)

Viewing Angle

65/65/45/65 (Typ.)(CR≥10)

Operating Mode

TN, Normally White, Transmissive

Support Color

262K 48% NTSC

Light Source

WLED [3S11P] , 20K hours , W/O Driver

Frame Rate

60Hz

Touch Panel

Without

Interface Type

Parallel RGB (1 ch, 6-bit) , 60 pins FPC

Power Supply

3.3/8.8/15/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)

Environment

Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C
