Samsun 34" 3440×1440 500cd/M2 Lcd Touch Display LTM340YP02-Q01

small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Samsun 34" 3440×1440 500cd/M2 Lcd Touch Display LTM340YP02-Q01

Product Details:
Place of Origin: China
Brand Name: samsung
Certification: Rohs,CE,FCC
Model Number: LTM340YP02-Q01
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week
Detailed Product Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 1.07B Colors
Model: WLED Style: Wide Screen High Resolution 3440*1440PIXELS
Brightness: 500cd Connector: 50PIN
Contrast Ratio: 3000:1 Working Time: 30k Hours
Input Voltage: 12V Signal Type: EPD
High Light:

500cd/M2 Lcd Touch Display


3440×1440 Lcd Touch Display



Samsun 34inch lcd model LTM340YP02-Q01 3440(RGB)×1440 109PPI 500 cd/m² ePD 50pin



Manufacturer SAMSUNG Model Name LTM340YP02-Q01
Screen Size 34 inch Screen Type LCM , a-Si TFT-LCD
Pixel Number 3440(RGB)×1440 109PPI Arrangement RGB Vertical Stripe
Active Area(mm) 799.8 × 334.8 (H×V) Outline(mm) 811.5 × 357 × 18.1 (H×V×D)
Bezel Area(mm) - Treatment Antiglare (Haze 2.3%), Hard coating (2H)
Luminance 300 cd/m² (Typ.) Contrast Ratio 3000 : 1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10)  Response 14 (Typ.)(G to G) ms
Good View at Symmetry Work Mode PVA, Normally Black, Transmissive
Color Depth 16.7M 99% sRGB Backlight 4 strings WLED , 30K hours , No Driver
Mass 5.94Kgs (Max.) Used for
Refresh Rate 60Hz Touchscreen Without
Signal Type eDP (4 Lanes) , 50 pins Connector
Voltage Supply 12.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C



LTM340YP02-Q01 is a 34" diagonal a-Si TFT-LCD display panel product from Samsung Display Co., Ltd. (hereafter called SAMSUNG), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: sRGB, Curved Display, WLED Backlight, Reverse I/F, Matte , 2000R. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q4, 2015, Now this model is discontinued.  We inputted this model's specification on Jun 8 2016 for the first time, and the latest update on Jan 18 2020. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with SAMSUNG or it's agent to learn lateast production and specification detail of LTM340YP02-Q01. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
