Innolux 50 Inch LCD TV Panel with 400cd/m2 Brightness and 3480*2160 Resolution for High-Quality Display

Innolux 50 Inch LCD TV Panel with 400cd/m2 Brightness and 3480*2160 Resolution for High-Quality Display

Innolux 50 Inch LCD TV Panel with 400cd/m2 Brightness and 3480*2160 Resolution for High-Quality Display

Brand Name: Innolux
Model Number: V500DK2-KS1
MOQ: 10pcs
Price: Negotiation
Payment Terms: T/T,W,Western Union,MoneyGram
Supply Ability: 3000pcs per week
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
Rohs,CE,FCC
Quality:
Brand New Original
Package:
Original Industrial Packing
Material:
Glass Oled
Color:
16.7m Colors
Model:
WLED
Style:
Wide Screen High Resolution 3480*2160
Brightness:
400cd
Connector:
51PIN
Contrast Ratio:
4000:1
Working Time:
30k Hours
Packaging Details:
Industrial packing
Highlight:

lcd tv display panel

,

led tv display panel

Product Description
WLED Model Flat Screen TV Panel Innolux 50" V500DK2-KS1 3480*2160 51 Pin 400cd/m²
Product Specifications
Manufacturer Innolux Model Name V500DK2-KS1 Rev.C8
Screen Size 50 inch Screen Type LCM, a-Si TFT-LCD
Pixel Number 3840(RGB)*2160 (UHD) Arrangement RGB Vertical Stripe
Active Area 1095.84 * 616.41 (H*V) Outline Dimensions 1115.04 * 638.41 * 28.6 (H*V*D)
Bezel Area 1103.04 * 622.41 (H*V) Surface Treatment Antiglare (Haze 1%), Hard coating (3H)
Luminance 400 cd/m² (Typ.) Contrast Ratio 4000 : 1 (Typ.) (TM)
Viewing Angle 88/88/88/88 (Typ.)(CR≥20) Response Time 9.5 (Typ.)(G to G) ms
Viewing Mode Symmetry Work Mode Super MVA, Normally Black, Transmissive
Color Depth 1.07B 72% (CIE1931) Backlight WLED, 30K hours, With LED Driver
Weight 11.7/12.3Kgs (Typ./Max.) Refresh Rate 120Hz
Touchscreen Without Signal Type V-by-One 8 lane, Connector, 51 pins
Voltage Supply 12.0V (Typ.) Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C
Innolux 50 Inch LCD TV Panel with 400cd/m2 Brightness and 3480*2160 Resolution for High-Quality Display 0
Product Overview
The V500DK2-KS1 Rev.C8 is a 50-inch diagonal a-Si TFT-LCD display panel from Innolux Corporation, featuring an integrated WLED backlight system with LED driver and no touch screen capability. This panel operates within a temperature range of 0~50°C and can be stored at temperatures from -20~60°C.
Key Features
  • High Color Gamut for vibrant color reproduction
  • Antiglare Surface with hard coating (3H) protection
  • 10-bit color depth for smooth gradients
  • Wide Viewing Angle with symmetrical 88/88/88/88 performance
  • 3D Display capability
  • Landscape orientation design
  • White LED Backlight with 30,000-hour lifespan
  • Wide Aspect Ratio for modern display applications
  • Signal Interface Position Reverse configuration
  • 120Hz Scan frequency for smooth motion
  • Center Luminance of White 3D: 60 cd/m²
Application & Production Information
This display panel is recommended for TV sets and similar applications. According to available information, mass production of this model began in Q4 2013, and the model is currently discontinued. Specifications were first recorded on February 25, 2014, with the latest update on January 22, 2017.
Important Note: For integration of the V500DK2-KS1 Rev.C8 LCM into future products, we strongly recommend contacting Innolux or their authorized agents to verify current production status and obtain the latest specification details. The production status information provided here is for reference only and should not be used as the sole basis for decision-making.
