27 inch 1920*1080 Pixels LCD Display with 1000:1 Contrast Ratio and Wide Viewing Angle

Name: 27 inch 1920*1080 Pixels LCD Display with 1000:1 Contrast Ratio and Wide Viewing Angle
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: MV270FHB-N20
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	MV270FHB-N20
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1080

Brightness:

250cd

Connector:

Contrast Ratio:

1000:1

Working Time:

30k Hours

Packaging Details:

Industrial packing

Highlight:

touch screen computer monitor

high resolution touch screen monitor

Product Description

27" HD LCD Display Panel MV270FHB-N20

Product Overview

27-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring high color gamut, antiglare surface, and wide viewing angle capabilities.

Technical Specifications

Manufacturer	BOE
Model Name	MV270FHB-N20
Screen Size	27.0 inch
Screen Type	CELL, a-Si TFT-LCD
Resolution	1920×1080 (FHD)
Active Area	597.888 × 336.312 mm (H×V)
Outline Dimensions	607.048 × 346.642 mm (H×V×D)
Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	89/89/89/89 (Typical, CR≥10)
Response Time	14 ms (Typical, G to G)
Color Depth	16.7M colors, 72% (CIE1931)
Refresh Rate	60Hz
Signal Type	LVDS (2 ch, 8-bit), Connector, 30 pins
Operating Voltage	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Weight	625g (Typical)

Key Features

High Color Gamut for vibrant color reproduction
Antiglare Surface treatment for reduced reflections
Wide Viewing Angle for consistent image quality
Landscape orientation with wide aspect ratio
CELL configuration (backlight and touchscreen not included)

Recommended Applications

Ideal for desktop monitors and professional display applications requiring high-quality visual performance.

Production Status: Mass production began Q1 2016. Current production status is active. Specifications last updated May 16, 2019.

Important Notice: Contact BOE or their authorized agents for the latest production status and specification details before integration. Production status information is for reference only and should not be used as the sole basis for decision making.

Quality Assurance: All LCD display modules undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.
