Innoux Industrial Panel Pc Touch Screen 15'' 500cd/m2 Brightness G150XNE-L01 L03

Brand Name:	INNOLUX
Model Number:	G150XNE-L01
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

KOREA

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

Style:

Wide Screen High Resolution 800*600

Brightness:

450cd

Connector:

20pin

Contrast Ratio:

1500:1

Working Life:

70K Hours

Supply Ability:

3000pcs per week

Highlight:

industrial panel pc touch screen

industrial computer monitor

Product Description

Manufacturer

Innolux

Model Name

G150XNE-L01

Screen Size

15.0 inch

Screen Type

LCM , a-Si TFT-LCD

Pixel Number

1024(RGB)×768 (XGA)

Arrangement

RGB Vertical Stripe

Active Area(mm)

304.128 × 228.096 (H×V)

Outline(mm)

326.5 × 253.5 × 9.6 (H×V×D)

Bezel Area(mm)

307.4 × 231.3 (H×V)

Treatment

Antiglare, Hard coating (3H)

Luminance

500 cd/m² (Typ.)

Contrast Ratio

2500 : 1 (Typ.) (TM)

Viewing Angle

88/88/88/88 (Typ.)(CR≥10)

Response

13/5 (Typ.)(Tr/Td) ms

Good View at

Symmetry

Work Mode

NPVA, Normally Black, Transmissive

Color Depth

262K/16.7M 72% (CIE1931)

Backlight

WLED , 70K hours , With LED Driver

Mass

0.97/1.00Kgs (Typ./Max.)

Used for

Refresh Rate

60Hz

Touchscreen

Without

Signal Type

LVDS (1 ch, 6/8-bit) , Connector , 20 pins

Voltage Supply

3.3V (Typ.)

Max. Ratings

Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 80 °C
Innolux Corporation (hereafter called Innolux) G150XNE-L01 is a 15.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -40 ~ 85°C . It's general features are summarized by einklcd in the following: High Color Gamut, Antiglare Surface, 6/8 bit Selectable, Wide Viewing Angle, Landscape type, Wide Temperature, White LED Backlight, Lamp life ≥ 70K hours, Normal Signal Interface Position, 180 Reverse , PSWG. Based on its features,einklcd recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q1, 2017, Now this model is in production. We inputted this model's specification on Aug 24 2016 for the first time, and the latest update on Apr 16 2019. If you want to embed G150XNE-L01 LCM in your future product, Einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The G150XNE-L01 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

It's 500cd/m2 lcd MODEL for industrial field use.

All our LCD LED screen monitor module panel products will be full test one by one before sending .
