LG 18.5 Inch Industrial LCD Panel with 300cd/m2 Brightness and 30 Pin Connector for Medical and TV Use

Name: LG 18.5 Inch Industrial LCD Panel with 300cd/m2 Brightness and 30 Pin Connector for Medical and TV Use
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LC185EXN-SCA1
Price: 43.00 USD
Availability: InStock

Brand Name:	lg
Model Number:	LC185EXN-SCA1
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

korea

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1366*768

Brightness:

300cd

Connector:

30pin

Contrast Ratio:

1000:1

Working Life:

30K Hours

Packaging Details:

Industrial packing

Highlight:

industrial panel pc touch screen

industrial computer monitor

Product Description

LG 18.5" Medical Industrial LCD Panel TV - Model LC185EXN-SCA1

Product Overview

High-performance 18.5-inch LCD panel designed for demanding medical, industrial, and television applications. Features 1366*768 WXGA resolution with 300 cd/m² brightness for clear visibility in various lighting conditions.

Technical Specifications

Manufacturer	LG Display
Model Name	LC185EXN-SCA1
Screen Size	18.5 inch
Screen Type	LCM, a-Si TFT-LCD
Resolution	1366(RGB)*768 (WXGA)
Pixel Arrangement	RGB Vertical Stripe
Active Area	409.8 * 230.4 mm (H*V)
Outline Dimensions	430.4 * 254.6 * 14.9 mm (HVD)
Luminance	300 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	89/89/89/89 (CR≥10)
Response Time	9 ms (G to G, Typical)
Display Technology	S-IPS, Normally Black, Transmissive
Color Depth	16.7M colors, 68% (CIE1931)
Backlight	WLED, 30K hours lifespan, With LED Driver
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	LVDS (1 ch, 8-bit), 30-pin Connector
Voltage Supply	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Weight	1.26 kg (Typical) / 1.35 kg (Maximum)

Surface Treatment

Antiglare coating (Haze 13%) with hard coating (3H) for durability and reduced reflections.

Key Features

300 cd/m² high brightness for industrial, medical, and TV applications
Original LG LCD panel in factory packaging
S-IPS technology for superior viewing angles and color accuracy
WLED backlight with 30,000-hour lifespan
Robust construction for demanding environments

All our LCD/LED screen monitor module panel products undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.
