| Brand Name: | LG |
| Model Number: | LC430EQE-FHA1 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Manufacturer |
|---|
| Screen Size |
| Pixel Number |
| Active Area(mm) |
| Bezel Area(mm) |
| Luminance |
| Viewing Angle |
| Good View at |
| Color Depth |
| Mass |
| Refresh Rate |
| LG Display |
| 43 inch |
| 3840(RGB)×2160 (UHD) |
| 941.184 × 529.416 (H×V) |
| 946.2 × 534.4 (H×V) |
| 350 (Typ.)(cd/m²) |
| 89/89/89/89 (Min.)(CR≥10) |
| Symmetry |
| 16.7M 72% (CIE1931) |
| 7.50/8.50Kgs (Typ./Max.) |
| 60Hz |
| Model Name |
| Screen Type |
| Arrangement |
| Outline(mm) |
| Treatment |
| Contrast Ratio |
| Work Mode |
| Response |
| Backlight |
| Used for |
| Touchscreen |
| LC430EQE-FHA1 |
| LCM , a-Si TFT-LCD |
| RGB Vertical Stripe |
| 962 × 554.8 × 37.6 (H×V×D) |
| Antiglare (Haze 44%), Hard coating (2H) |
| 1000 : 1 (Typ.) (TM) |
| IPS, Normally Black, Transmissive |
| 6 (Typ.)(G to G) ms |
| WLED , 30K hours , No Driver |
|
|
| Without |
| Signal Type | V-by-One 8 lane , Connector , 51 pins |
|---|---|
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
