Innolux 31.5 Inch 4K UHD LCD TV Panel LED TV Module with MVA Work Mode LCD Screen Display

Name: Innolux 31.5 Inch 4K UHD LCD TV Panel LED TV Module with MVA Work Mode LCD Screen Display
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: M315DJJ-K30
Price: 30.00 USD
Availability: InStock

Brand Name:	innolux
Model Number:	M315DJJ-K30
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Led

Color:

Black Or Silver

Model:

TV Module,LED

Style:

Wide Screen High Resolution 3840*2160

Packaging Details:

Industrial packing

Highlight:

flat screen tv panel

lcd tv display panel

Product Description

Black / Silver 31.5 Inch 4K LCD TV Screen Panel, M315DJJ K30 LCD Flat Panel

Innolux 31.5 Inch 4K LED TV module M315DJJ-K30 LCD Screen Display M315DJJ K30 31.5" Panel

Technical Specifications

Manufacturer	Innolux
Model Name	M315DJJ-K30
Screen Size	31.5 inch
Screen Type	LCM, a-Si TFT-LCD
Resolution	3840(RGB)*2160 (UHD)
Pixel Arrangement	RGB Vertical Stripe
Active Area	698.4 * 392.85 mm (H*V)
Outline Dimensions	717.4 * 413.85 * 18.9 mm (HVD)
Bezel Area	703.4 * 397.85 mm (H*V)
Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)
Luminance	300 cd/m² (Typical)
Contrast Ratio	3000:1 (Typical)
Viewing Angle	89/89/89/89 (Typical, CR≥10)
Response Time	9.5 ms (Typical, G to G)
Display Mode	MVA, Normally Black, Transmissive
Color Depth	1.07B 95% (CIE1931)
Backlight System	4 strings WLED, 30K hours lifespan, No Driver required
Weight	3.46±0.18 kg
Refresh Rate	60Hz
Touchscreen	Without
Signal Interface	V-by-One 8 lane, Connector, 51 pins
Operating Voltage	12.0V (Typical)
Temperature Range	Storage: -20°C to 60°C Operating: 0°C to 50°C

Product Features

Ultra HD 4K Resolution - 3840*2160 pixels for exceptional image clarity
MVA Technology - Superior viewing angles and color reproduction
WLED Backlight - Energy efficient with 30,000 hours lifespan
Anti-Glare Surface - 25% haze treatment with 3H hard coating
V-by-One Interface - High-speed 8-lane signal transmission
Wide Temperature Range - Reliable operation from 0°C to 50°C

Quality Assurance: All our LCD LED screen monitor module panel products undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.
