AUO P430HVN01.1 43 Inch LCD Display with 1920x1080 FHD Resolution and 400 cd/m² Brightness

Name: AUO P430HVN01.1 43 Inch LCD Display with 1920x1080 FHD Resolution and 400 cd/m² Brightness
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: P430HVN01.1
Price: 30.00 USD
Availability: InStock

Brand Name:	AUO
Model Number:	P430HVN01.1
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Packaging Details:

Industrial packing

Highlight:

large flat screen monitor

large display monitor

Product Description

AUO P430HVN01.1 RGB Large Display Monitor

AUO 43-inch brand new original LCD panel featuring 1920×1080 Full HD resolution, 400 cd/m² brightness, and LVDS interface. This professional-grade display offers exceptional image quality for industrial and commercial applications.

Technical Specifications

Panel Brand	AUO	Panel Model	P430HVN01.1
Panel Size	43 inch	Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD	Pixel Format	RGB Vertical Stripe
Display Area	940.896(W)×529.254(H) mm	Bezel Opening	945.9(W)×534.2(H) mm
Outline Size	963.7(W)×552(H)×27.2(D) mm	Surface	Antiglare, Hard coating (3H)
Brightness	400 cd/m² (Typ.)	Contrast Ratio	3000:1 (Typ.) (TM)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Display Mode	AMVA3, Normally Black, Transmissive
Best View on	Symmetry	Response Time	8ms (Typ.)(G to G)
Display Colors	16.7M 72% (CIE1931)	Lamp Type	WLED, 60K hours, With LED Driver
Frequency	60Hz	Touch Screen	Without
Weight	9.00Kgs (Typ.)	Application	Industrial Display

Interface & Environmental Specifications

Signal Interface	LVDS (2 ch, 8-bit), 51 pins, Connector
Input Voltage	12.0V (Typ.)
Operating Temperature	0 ~ 50 °C
Storage Temperature	-20 ~ 60 °C

Key Features

43-inch large format display with Full HD 1920×1080 resolution
High brightness 400 cd/m² for excellent visibility
Wide 89/89/89/89 viewing angles with symmetry
AMVA3 technology with 3000:1 contrast ratio
Antiglare hard coating surface (3H hardness)
Long-life WLED backlight with 60,000-hour lifespan
LVDS interface with connector for easy integration

Quality Assurance: All original products undergo comprehensive testing before shipment. Detailed specifications are available upon request - please contact us for complete technical documentation.
