11.6 Inch LCD Display Panel 1366x768 Pixels 30PIN IPS LCD Module Laptop LCD Screen NV116WHM-N49 V8.0

Name: 11.6 Inch LCD Display Panel 1366x768 Pixels 30PIN IPS LCD Module Laptop LCD Screen NV116WHM-N49 V8.0
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: NV116WHM-N49 V8.0
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	NV116WHM-N49 V8.0
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1366*768pixels

Style:

30PIN IPS

Brightness:

250CD/M2

Color:

16.7M

Contrast Ratio:

1000 :1

Working Life:

15K Hours

Screen Size:

11.6inch

Touch Screen:

Without

Packaging Details:

Industrial packing

Highlight:

11.6 Inch LCD Display Panel

1366x768 Pixels LCD Module

30PIN IPS Laptop LCD Screen

Product Description

Product Overview

The NV116WHM-N49 (Product Code: BOE0979) is an 11.6-inch diagonal a-Si TFT-LCD display panel manufactured by BOE Technology Group Co., Ltd. It features an integrated WLED backlight system with LED driver and does not include a touch screen.

This module operates within a temperature range of 0 ~ 50°C and can be stored between −20 ~ 60°C. It withstands a maximum vibration level of 1.5G (14.7 m/s²). Key characteristics include WLED backlight, integrated LED driver, reverse interface, matte surface, and eDP1.2 connectivity.

Based on its specifications, this model is recommended for laptop applications. According to available records, mass production began in Q3 2020, and the model remains in production. Specifications were first entered on December 25, 2020, with the latest update on October 10, 2026.

If you intend to embed this LCM in a future product, it is strongly recommended that you contact BOE or its agent to confirm the latest production and specification details. Production status shown here is for reference only and should not be used as the sole basis for decision-making.

Product Image

Specifications

Manufacturer	BOE
Model No.	NV116WHM-N49
Screen Size	11.6 inch
Screen Type	a-Si TFT-LCD, LCM
Number of Dots	1366 (RGB) × 768, WXGA, 16:9
Dot Layout	RGB Vertical Stripe
Active Area	256.125 × 144 mm (H×V)
Outline Area	278 × 168 × 3 mm (H×V×D)
Weight	200g (Max.)
Surface Feature	Antiglare, Hard coating (3H)
Luminance	250 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/85/85 (Typ.) (CR≥10)
Response (ms)	20 (Typ.) (Tr+Td)
Good View at	Symmetry
Display Type	ADS, Normally Black, Transmissive
Display Colors	262K, 50% NTSC
Outline Shape	Slim (PCBA Flat, T≤3.2mm)
Backlight	8S3P WLED, 15K hrs, With LED Driver
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	eDP (1 Lane), eDP1.2, HBR1 (2.7G/lane), 30 pins 0.5mm Connector
Voltage Supply	3.3V (Typ.)
Max. Ratings	Storage Temp. −20 ~ 60 °C \| Operating Temp. 0 ~ 50 °C
