BOE 18.5 Inch LCD Module with 1366x768 Resolution 200 cd/m² Brightness and 30pin Connector

Name: BOE 18.5 Inch LCD Module with 1366x768 Resolution 200 cd/m² Brightness and 30pin Connector
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: MT185WHM-N10
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	MT185WHM-N10
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

200ccd/m2

Resolution:

1366*768pixels

Contrast Ratio:

600:1

Color:

16.7M

Working Life:

30k Hours

Connector:

30P

Touch Panel:

Without

Working Voltage:

5.0V

Packaging Details:

Industrial packing

Highlight:

1366x768 Resolution LCD Module

200 cd/m² Brightness TFT-LCD Display Panel

30pin Connector Desktop Monitor LCD

Product Description

BOE 18.5 Inch Desktop Monitor LCD Module MT185WHM-N10

Product Overview

MT185WHM-N10 is an 18.5-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring 1366×768 WXGA resolution, 200 cd/m² brightness, and 30-pin LVDS interface. This LCD module includes an integral WLED backlight system and is designed for desktop monitor applications.

Key Features

WLED Backlight with 30,000 hours lifespan
Matte surface with anti-glare coating (Haze 25%)
Hard coating (3H) for durability
GOA Dual Gate technology for cost efficiency
75Hz frame rate for smooth display
16.7 million colors with 72% NTSC color gamut

Technical Specifications

Brand	BOE
Model	MT185WHM-N10
Diagonal Size	18.5 inch
Display Type	a-Si TFT-LCD, LCM
Resolution	1366(RGB)×768, WXGA, 16:9
Active Area	409.8(H)×230.4(V) mm
Physical Size	430.4(H)×254.6(V)×11.4(D) mm
Mass	1.31 kg (Typical)
Brightness	200 cd/m² (Typical)
Contrast Ratio	600:1 (Typical)
Response Time	1.5/3.5 ms (Typical, Tr/Td)
Viewing Angle	45/45/25/40 (Typical, CR≥10)
Operating Mode	TN, Normally White, Transmissive
Power Consumption	10.3/11.1W (Typical/Maximum)
Interface	LVDS (1 channel, 8-bit), 30-pin connector
Power Supply	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Vibration Resistance	Maximal 1.5G (14.7 m/s²)

Important Note: This model entered mass production in Q3 2015 and is currently in production. For the latest production status and detailed specifications for integration into your products, we strongly recommend contacting BOE or their authorized agents directly. The information provided here is for reference only and should not be used as the sole basis for decision-making.
