LG 27Inch AM-OLED Desktop LCD Monitor with 2560x1440Pixels Resolution PC LCD Module

Name: LG 27Inch AM-OLED Desktop LCD Monitor with 2560x1440Pixels Resolution PC LCD Module
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LW270AHQ-ERG2
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	LW270AHQ-ERG2
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

2560*1440pixels

Style:

112PIN IPS

Brightness:

150CD/M2

Color:

1.07b

Contrast Ratio:

1500 :1

Working Life:

30K Hours

Screen Size:

27inch

Touch Screen:

Without

Packaging Details:

Industrial packing

Highlight:

27Inch LCD Display Panel

2560x1440Pixels PC LCD Module

AM-OLED Desktop LCD Monitor

Product Description

LG 27-Inch Desktop LCD Display Panel LW270AHQ-ERG2

The LW270AHQ-ERG2 is a 27.0-inch diagonal AM-OLED display panel from LG Display Co., Ltd. This self-emitting display features Quad-HD resolution (2560×1440 pixels) with 110 PPI and operates without a touch screen. Engineered for professional and gaming applications, this panel delivers exceptional color accuracy and performance.

Key Features

27-inch AM-OLED display with 2560×1440 Quad-HD resolution
98% DCI-P3 color gamut and 1.07 billion colors
240Hz refresh rate with embedded MEMC circuit
HDR600, HDR800 (10%), and HDR1000 (3.0%) support
150 cd/m² typical luminance with 1,500,000:1 contrast ratio
0.1ms response time (typical G to G)
Anti-glare treatment with 35% haze and 2.0% reflection
V-by-One 16-lane interface with 112-pin connector

Technical Specifications

Brand & Model	LG Display LW270AHQ-ERG2
Panel Type	AM-OLED, Full Module
Diagonal Size	27.0 inches
Resolution	2560×1440 pixels (Quad-HD), 110 PPI
Active Area	590.42mm × 333.72mm
Outline Dimensions	604.42mm × 350.62mm
Pixel Format	RGBW Vertical Stripe
Frame Rate	240Hz (with embedded MEMC circuit)
Interface	V-by-One 16 lane, 112-pin connector
Power Supply	12/19.5V (Typical VDD/ELVDD)
Weight	3.20kg (Typical) / 3.4kg (Maximum)
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 60°C
Light Source Life	30,000 hours

Application Areas

This display panel is specifically designed for desktop monitors and gaming applications, delivering superior performance for professional and entertainment use cases.

Production Note: Mass production began in Q3 2022. For the latest production status and detailed specifications, we strongly recommend contacting LG Display or their authorized agents directly. The information provided is for reference only and should not be used as the sole basis for decision-making.
