Sharp 7.9Inch LCD Module with 1536X2048P Resolution and 460cd/M2 Brightness for 3D Printers

Name: Sharp 7.9Inch LCD Module with 1536X2048P Resolution and 460cd/M2 Brightness for 3D Printers
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LQ079L1SX01
Price: 30.00 USD
Availability: InStock

Brand Name:	Sharp
Model Number:	LQ079L1SX01
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1536*2048pixels

Style:

50PIN IPS

Brightness:

460CD/M2

Color:

16.7M

Contrast Ratio:

1000 :1

Working Life:

15K Hours

Type:

Lcm

Size:

7.9Inch

Lamp Type:

LCM

Voltage:

5.6V

Packaging Details:

Industrial packing

Highlight:

7.9Inch LCD Module

1536X2048P TFT-LCD Display

460cd/M2 PC LCD Panel

Product Description

Sharp 7.9-Inch Tablet LCD Display LQ079L1SX01

The LQ079L1SX01 is a 7.9-inch diagonal Oxide TFT-LCD display panel from Sharp Corporation featuring an integrated WLED backlight system. This high-resolution display is designed for applications including tablets and 3D printers, offering excellent image quality and performance.

Key Specifications

Brand: Sharp

Model: LQ079L1SX01

Diagonal Size: 7.9"

Panel Type: Oxide TFT-LCD, LCM

Resolution: 1536×2048 QXGA

Pixel Density: 325 PPI

Brightness: 460 cd/m²

Contrast Ratio: 1000:1

Viewing Angle: 85/85/85/85

Response Time: 35 ms

Color Depth: 16.7M colors

Refresh Rate: 60Hz

Interface: MIPI, 50-pin connector

Operating Voltage: 1.8/5.6/-5.6V

Operating Temp: -20°C to 60°C

Storage Temp: -30°C to 70°C

Weight: 65.0g

Technical Features

This display utilizes IPS technology with normally black, transmissive characteristics. It features RGB vertical stripe pixel format and includes a 6S4P WLED backlight system without driver. The panel supports various refresh rate configurations including 120Hz with embedded MEMC circuit.

Application Areas

Primarily designed for tablet computers and 3D printer displays, this high-resolution LCD panel delivers exceptional clarity and color accuracy for demanding industrial and consumer applications.

Important Note: This model entered mass production in Q3 2014 and is currently discontinued. For integration into new products, we strongly recommend contacting Sharp or their authorized agents for the latest production status and specifications. Information provided here is for reference only and should not be used as the sole basis for decision-making.
