BOE 27inch lcd model MV270QUM-N20 3840*2160Pixels 163PPI PC LCD Module 30PIN Desktop monitor

BOE Technology Group Co., Ltd. (hereafter called BOE) MV270QUM-N20 is a 27.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.2G (11.76 m/s²). It's general features are summarized by einklcd in the following: sRGB, 3-side boderless, WLED Backlight, Reverse I/F, 10 bit, Matte , 3-side Borderless, 100% sRGB. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q4, 2017, Now this model is in production.  We inputted this model's specification on Sep 28 2017 for the first time, and the latest update on Sep 2 2024. If you want to embed MV270QUM-N20 LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's distributor to learn lateast production and specification detail. The MV270QUM-N20 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand BOE

Model P/N: MV270QUM-N20
Diagonal Size: 27.0"

Panel Type: a-Si TFT-LCD, LCM
Resolution: 3840(RGB)×2160, UHD 163PPI

Pixel Format: RGB Vertical Stripe
Active Area 596.736(W)×335.664(H) mm

Bezel Opening-
Outline (mm)608.8 × 353.3 × 13.9 (H×V×D)

Treatment Antiglare (Haze 25%), Hard coating (3H)
Luminance 350 cd/m² (Typ.)

Contrast Ratio 1000 : 1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Response TBD ms
Good View at Symmetry

Work Mode:ADS, Normally Black, Transmissive
Color Depth1.07B 100% sRGB

Backlight:19S4P WLED , 30K hours , No Driver
Mass 3.22Kgs (Typ.)

Used for Desktop Monitor
Refresh Rate: 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC CircuitTouchscreenWithout
Signal TypeeDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector
Voltage Supply 10.0V (Typ.)
Max. Ratings

Storage Temp.: -20 ~ 60 °C

Operating Temp.: 0 ~ 50 °C
