AUO 8.9inch Stretched bar LCD Display C089KAN01.0 40Pin Monitor 1280*272pixels Outdoor Brightness lcd

The C089KAN01.0 is a 8.9 inch diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, without touch screen. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -40 ~ 95°C . It's general features are summarized by einklcd in the following: Wide Temperature, Ultra High Brightness, WLED Backlight, Bar Display, 180° Reverse, Matte . Based on its features, einklcd recommend that this model be applied to Outdoor High Brightness, Stretched Bar LCD, Automotive Display etc. According to the information stored in einklcd this model mass production on Q3, 2016 and last shippment on Q4, 2020, Now this model is discontinued.  We inputted this model's specification on Jun 21 2019 for the first time, and the latest update on May 22 2023. If you want to embed C089KAN01.0 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail. The C089KAN01.0 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand AUO

Model P/N:C089KAN01.0
Diagonal Size 8.9" (Native bar)

Panel Type: a-Si TFT-LCD, LCM
Resolution 1280(RGB)×272 147PPI

Pixel Format RGB Vertical Stripe
Active Area 220.032(W)×46.7568(H) mm

Bezel Opening-
Outline (mm) 231.292×62.3 (H×V×D)

Treatment: Anti glare
Luminance 1750 cd/m² (Typ.)

Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle 80/80/80/80 (Min.)(CR≥10) Left / Right / Up / Down

Response 9/11 (Typ.)(Tr/Td) ms
Good View at Symmetry Work ModeA HVA, Normally Black, Transmissive
Color Depth:16.7M

Backlight: WLED
Mass181.7±18g

Used for: Outdoor High Brightness Stretched Bar LCD ,Automotive Display
Refresh Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC CircuitTouchscreenWithout
Signal TypeLVDS (1 ch, 8-bit) , Connector 40 pins
Max.

RatingsStorage Temp.: -40 ~ 95 °C

Operating Temp.: -30 ~ 85 °C
