BOE 27inch Desktop lcd panel MV270QHM-NF2 2560*1440Pixels 108ppi 400CD/M2 10.0V 60pin PC LCD Module

Brand Name:	BOE
Model Number:	MV270QHM-NF2
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

korea

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

Style:

Wide Screen High Resolution 1920*1080Pixels

Brightness:

400cd

Connector:

60PIN

Contrast Ratio:

1000:1

Working Time:

30k Hours

Supply Ability:

3000pcs per week

Highlight:

27inch Desktop lcd panel

MV270QHM-NF2 Desktop lcd panel

400CD/M2 Desktop lcd panel

Product Description

BOE 27inch Desktop lcd panel MV270QHM-NF2 2560*1440Pixels 108ppi 400CD/M2 10.0V 60pin PC LCD Module

MV270QHM-NF2 is a 27.0" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: sRGB, 3-side boderless, 165Hz, WLED Backlight, Reverse I/F, 10 bit, Matte , 350nit, sRGB 99%, 3-Side, 1000:1, 178/178, 165Hz, 5ms, LBL. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Gaming etc. According to the information stored in einklcd this model mass production on Q2, 2022, Now this model is discontinued. We inputted this model's specification on Apr 28 2022 for the first time, and the latest update on Mar 6 2025. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of MV270QHM-NF2. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:BOE

Model P/N: MV270QHM-NF2
Diagonal Size: 27.0"Panel

Type: a-Si TFT-LCD, LCM
Resolution: 2560(RGB)×1440, Quad-HD 108PPI Pixel

Format :RGB Vertical Stripe
Active Area: 596.736(W)×335.664(H) mm

Bezel Opening-
Outline Dim.608.8(H)×355.1(V) ×15.7(D) mm

Treatment Antiglare, Hard coating (3H)
Luminance: 400 cd/m² (Typ.)

Contrast Ratio1000:1 (Typ.) (TM)
View DirectionSymmetry

Response Time: 5 (Typ.)(G to G)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Operating Mode: ADS, Normally Black, Transmissive
Support Color 1.07B 99% sRGB

Light Source: WLED [9S4P×2CN] , 30K hours , W/O Driver
Weight 2.31Kgs (Typ.)

Designed For Desktop Monitor Gaming
Frame Rate: 165Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit

Touch Panel: Without
Interface Type: eDP (8 Lanes) , HBR2 (5.4G/lane) , 60 pins Connector
Power Supply:10V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ;

Storage Temperature: -20 ~ 60 °C
