BOE 27inch 2560x1440Pixels 400CD/M2 PC LCD Module TFT-LCD Display Panel for Desktop Monitor

Name: BOE 27inch 2560x1440Pixels 400CD/M2 PC LCD Module TFT-LCD Display Panel for Desktop Monitor
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: MV270QHM-NF2
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	MV270QHM-NF2
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

korea

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

XGA

Style:

Wide Screen High Resolution 1920*1080Pixels

Brightness:

400cd

Connector:

60PIN

Contrast Ratio:

1000:1

Working Time:

30k Hours

Packaging Details:

Industrial packing

Highlight:

27inch Desktop lcd panel

MV270QHM-NF2 Desktop lcd panel

400CD/M2 Desktop lcd panel

Product Description

BOE 27-inch MV270QHM-NF2 LCD Panel

27-inch diagonal a-Si TFT-LCD display panel with 2560*1440 Quad-HD resolution, featuring 165Hz refresh rate, 99% sRGB color gamut, and 3-side borderless design. Ideal for desktop monitors and gaming applications.

Key Features

27-inch display with 2560*1440 resolution (108 PPI)
165Hz refresh rate for smooth gaming performance
99% sRGB color coverage with 10-bit color depth
400 cd/m² brightness with 1000:1 contrast ratio
3-side borderless design with matte anti-glare coating
5ms response time (G to G)
eDP interface with 60-pin connector

Technical Specifications

Panel Type	a-Si TFT-LCD
Active Area	596.736 * 335.664 mm
Outline Dimensions	608.8 * 355.1 * 15.7 mm
Viewing Angle	89/89/89/89 (CR≥10)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Power Supply	10V (Typical)
Weight	2.31 kg (Typical)
Backlight	WLED, 30,000 hours lifespan
Interface	eDP (8 Lanes), HBR2 (5.4G/lane)

Refresh Rate Technologies

165Hz: Native panel refresh rate
120Hz (60Hz Input): Embedded MEMC Circuit
120Hz+120Hz: 120Hz Panel + 120Hz Backlight
240Hz (60Hz Input): Embedded MEMC Circuit

Important Note: This model has been discontinued. For integration into future products, we strongly recommend contacting BOE or their authorized agents for the latest production status and specification details. The information provided is for reference only and should not be used as the sole basis for decision-making.
