AUO 17.3inch 1920x1080Pixels 300CD/M2 PC LCD Module B173HAN05.4 TFT-LCD Display

Name: AUO 17.3inch 1920x1080Pixels 300CD/M2 PC LCD Module B173HAN05.4 TFT-LCD Display
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: B173HAN05.4
Price: 30.00 USD
Availability: InStock

Brand Name:	AUO
Model Number:	B173HAN05.4
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

korea

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

XGA

Style:

Wide Screen High Resolution 1920*1080Pixels

Brightness:

300cd

Connector:

EPD 2 Lanes

Contrast Ratio:

1000:1

Working Time:

15k Hours

Packaging Details:

Industrial packing

Highlight:

300CD/M2 Desktop lcd panel

17.3inch Desktop lcd panel

B173HAN05.4 Desktop lcd panel

Product Description

AUO 17.3-inch Desktop LCD Panel B173HAN05.4

High-performance 17.3-inch LTPS TFT-LCD display module featuring 1920*1080 Full HD resolution, 360Hz refresh rate, and comprehensive gaming optimization features.

Key Features

17.3-inch diagonal LTPS TFT-LCD display
1920*1080 Full HD resolution (127 PPI)
360Hz ultra-high refresh rate
3ms gray-to-gray response time (with OD)
100% sRGB color gamut coverage
G-Sync / FreeSync / Adaptive Sync compatible
eDP 1.4a interface with 40-pin connector
300 cd/m² brightness with WLED backlight
Anti-glare hard coating (3H)

Technical Specifications

Model Number	B173HAN05.4 (AUOE295)
Panel Type	LTPS TFT-LCD with AHVA technology
Active Area	381.888 * 214.812 mm
Outline Dimensions	389.89 * 238.31 * 3.5 mm
Contrast Ratio	1000:1 (Typical)
Viewing Angle	85/85/85/85 (Left/Right/Up/Down)
Color Depth	16.7 million colors
Response Time	8ms (Typical Tr+Td), 3ms (G-to-G with OD)
Refresh Rate Options	360Hz native, 240Hz/120Hz with MEMC
Signal Interface	eDP 1.4a (4 lanes), 40-pin connector
Operating Voltage	3.3V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Vibration Resistance	1.5G (14.7 m/s²)
Backlight System	WLED with 15,000 hours lifespan, includes LED driver

Application Areas

Primarily designed for high-performance gaming laptops and professional desktop displays requiring exceptional refresh rates and color accuracy.

Product Image

Important Note: Production status information is for reference only. For integration into your products, please contact AUO or their authorized agents for the latest production details and specifications.
