| Brand Name: | auo |
| Model Number: | P320HVN06.0 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
AUO brand 32INCH Digital signage LCD Panel 51P 400CCD / M2 Computer Monitor P320HVN06.0 1920*1080Pixels 69PPI
P320HVN06.0 is a 32.0" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: sRGB, Landscape / Portrait, WLED Backlight, Matte . Based on its features, einklcd recommend that this model be applied to Digital Signage etc. According to the information stored in einlcd this model mass production on Q2, 2019 and last shippment on Q4, 2024, Now this model is in production. We inputted this model's specification on Jul 8 2019 for the first time, and the latest update on Apr 11 2024. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of P320HVN06.0. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
Brand: AUO
Model P/N: P320HVN06.0
Diagonal Size:32.0"
Panel Type: a-Si TFT-LCD, LCM
Resolution1920(RGB)×1080, FHD 69PPI Pixel
FormatRGB Vertical Stripe
Active Area: 698.4(W)×392.85(H) mm
Bezel Opening-
Outline Size 719.2(W)×413.7(H) ×26.3(D) mm
Surface Antiglare (Haze 2%), Hard coating (3H)
Brightness 400 cd/m² (Typ.)
Contrast Ratio: 4000:1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode AMVA3, Normally Black, Transmissive
Best View on Symmetry
Response Time 8 (Typ.)(G to G)
Display Colors1 6.7M 72% NTSC
Lamp Type: 12S4P WLED , 30K hours , Without Driver
Frequency 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch ScreenWithout
Panel Weight: 4.55Kgs
Application: Digital Signage
Signal Interface LVDS (2 ch, 8-bit) , 51 pins Connector
Input Voltage:12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ;
Storage Temp.: -20 ~ 60 °C
|
|
