AUO 16inch lcd model B160UAN02.H 1920* 1200Pixels PC LCD Module 30PIN 141PPI

Brand Name:	AUO
Model Number:	B160UAN02.H
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1900*1200 Ixels

Style:

FHD 30P

Brightness:

300 CCD M2

Color:

16.7M

Contrast Ratio:

1200 :1

Working Life:

15K Hours

Supply Ability:

3000pcs per week

Highlight:

30PIN PC LCD Module

16inch PC LCD Module

B160UAN02.H LCD Module

Product Description

AUO 16inch lcd model B160UAN02.H 1920* 1200Pixels PC LCD Module 30PIN 141PPI

The B160UAN02.H (Product Code: AUOE69B) is a 16.0 inch diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Einklcd in the following: sRGB, WLED Backlight, With LED Driver, Matte , eDP1.4, LBL, PSR1. Based on its features, einklcd recommend that this model be applied to Laptop etc. According to the information stored in einklcd this model mass production on Q2, 2022, Now this model is in production. We inputted this model's specification on Dec 26 2022 for the first time, and the latest update on Aug 3 2023. If you want to embed B160UAN02.H LCM in your future product,einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail. The B160UAN02.H production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand: AUO

Model P/N:B160UAN02.H
Diagonal Size:16.0"

Panel Type:a-Si TFT-LCD, LCM
Resolution:1920(RGB)×1200, WUXGA 141PPI Pixel

Format RGB

Vertical Stripe
Active Area:344.68(W)×215.42(H) mm

Bezel Opening-
Outline(mm)349.68 × 225.32 × 5 (H×V×D)

TreatmentAntiglare, Hard coating (3H)
Luminance:300 cd/m² (Typ.)

Contrast Ratio1200 : 1 (Typ.) (TM)
Viewing Angle85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down

Response25 (Typ.)(Tr+Td) ms
Good View at Symmetry

Work Mode: AHVA, Normally Black, Transmissive
Color Depth:16.7M 100% sRGB

Backlight :WLED , 15K hours , With LED Driver
Outline Shape: Slim (PCBA Bent, T≤3.0mm)Used forLaptop
Refresh Rate: 60Hz

Touch screen :Without
Signal Type: eDP (2 Lanes) , eDP1.4 , 30 pins Connector
Voltage Supply:3.3V (Typ.)
Max. Ratings

Storage Temp.: -20 ~ 60 °C

Operating Temp.: 0 ~ 50 °C
