LP097X02-SLQ1 9.7 Inch LCD Screen 1024x768 Pixels 30PIN Display Panel for Pad and Laptop

Name: LP097X02-SLQ1 9.7 Inch LCD Screen 1024x768 Pixels 30PIN Display Panel for Pad and Laptop
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LP097X02-SLQ1
Price: 30.00 USD
Availability: InStock

Brand Name:	LG
Model Number:	LP097X02-SLQ1
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

400ccd/m2

Resolution:

1024*768pixels

Contrast Ratio:

800:1

Color:

262k

Working Life:

10k Hours

Connector:

30P

Touch Panel:

Without

Packaging Details:

Industrial packing

Highlight:

9.7inch LCD Screen

LP097X02-SLQ1 LCD Screen

Touch Panel For Pad Laptop

Product Description

LG LP097X02-SLQ1 9.7-inch LCD Display Panel

High-quality 9.7-inch LCD screen with 1024*768 XGA resolution and 132 PPI pixel density. This LG display panel features a 30-pin LVDS interface and is designed for tablet and laptop applications.

Product Overview

The LP097X02-SLQ1 is a 9.7-inch diagonal a-Si TFT-LCD display panel manufactured by LG Display, featuring an integrated WLED backlight system. This glossy display panel was originally designed for iPad 2 and similar tablet devices.

Technical Specifications

Display Model	LP097X02-SLQ1 (Alias: LP097X02 (SL)(Q1))
Brand	LG
Diagonal Size	9.7 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	1024(RGB)*768 (XGA), 132 PPI
Active Area	196.608(W) * 147.456(H) mm
Outline Dimensions	210.32(W) * 164.37(H) * 5.22(D) mm
Brightness	400 cd/m² (Typical)
Contrast Ratio	800:1 (Typical)
Viewing Angle	89/89/89/89 (Left/Right/Up/Down, CR≥10)
Display Mode	H-IPS, Normally Black, Transmissive
Response Time	35 ms (Typical, Tr+Td)
Display Colors	262K, 51% NTSC
Backlight	6S6P WLED, 10K hours lifespan, Without Driver
Refresh Rate	60Hz
Touch Screen	Without
Panel Weight	143g (Maximum)
Signal Interface	LVDS (1 channel, 6-bit), 30-pin Connector
Input Voltage	3.3V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Key Features

H-IPS technology for superior viewing angles
WLED backlight system for energy efficiency
Glossy surface with hard coating (2H) and antireflection treatment
Compact and lightweight design at 143g maximum weight
30-pin LVDS interface for reliable connectivity

Application

Primarily designed for tablet and portable computing devices. Compatible with iPad 2 and similar tablet platforms.

Important Note: This model has been discontinued. For current production status and latest specifications, please contact LG Display or their authorized agents directly. The information provided here is for reference purposes only.
