Innolux 31.5inch LCD Display Panel with 3840x2160 Pixels 300 cd/m² Brightness and 51PIN Connector for Desktop Monitor

Name: Innolux 31.5inch LCD Display Panel with 3840x2160 Pixels 300 cd/m² Brightness and 51PIN Connector for Desktop Monitor
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: M315DJJ-K30
Price: 30.00 USD
Availability: InStock

Brand Name:	Innolux
Model Number:	M315DJJ-K30
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

300ccd/m2

Resolution:

3840*2160pixels

Contrast Ratio:

3000:1

Color:

1.07B

Working Life:

30k Hours

Connector:

51P

Touch Panel:

Without

Packaging Details:

Industrial packing

Highlight:

31.5inch Desktop monitor

3840x2160Pixels Desktop monitor

M315DJJ-K30 laptop lcd screen

Product Description

Innolux 31.5-inch Desktop Monitor M315DJJ-K30 LCD Screen

High-performance 32.0-inch diagonal a-Si TFT-LCD display panel with 3840*2160 UHD resolution and 139 PPI pixel density. Features WLED backlight system, 51-pin connector, and 12V voltage supply.

Product Overview

The M315DJJ-K30 from Innolux Corporation is a professional-grade LCD panel featuring integral WLED backlight system without backlight driver or touch screen. This model is recommended for desktop monitor applications and includes advanced features like DCI-P3 color gamut, 10-bit color depth, and AMD FreeSync compatibility.

Key Specifications

Brand	Innolux
Model Number	M315DJJ-K30
Diagonal Size	32.0 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	3840(RGB)*2160 (UHD), 139 PPI
Active Area	698.4 * 392.85 mm
Outline Dimensions	717.4 * 413.85 * 18.9 mm
Luminance	300 cd/m² (Typical)
Contrast Ratio	3000:1 (Typical)
Viewing Angle	89/89/89/89 (Left/Right/Up/Down)
Response Time	9.5 ms (G to G, Typical)
Color Depth	1.07B colors, 98% DCI-P3
Refresh Rate	60Hz (120Hz with MEMC Circuit)
Signal Interface	V-by-One 8 lane, 51 pins
Voltage Supply	12.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Weight	3.46±0.18 kg

Advanced Features

MVA technology with normally black, transmissive operation
Antiglare treatment with hard coating (3H hardness)
WLED backlight with 30,000 hours lifespan
Embedded MEMC circuit for enhanced motion performance
AMD FreeSync compatibility for smooth gaming
Maximal vibration level: 1.5G (14.7 m/s²)

Product Images
