AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI 1.07B Color 51pin

AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI  1.07B Color 51pin
AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI  1.07B Color 51pin
AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI  1.07B Color 51pin AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI  1.07B Color 51pin AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI  1.07B Color 51pin

Large Image :  AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI 1.07B Color 51pin

Product Details:
Place of Origin: China
Brand Name: AUO
Certification: Rohs,CE,FCC
Model Number: T430QVN03.0
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week

AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI 1.07B Color 51pin

Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Brightness: 350ccd/m2
Resolution: 3840*2160pixels Contrast Ratio: 4000:1
Color: 1.06B Working Life: 30k Hours
Connector: 51P Touch Panel: Without

AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI 1.07B Color 51pin



AU Optronics Corp. (hereafter called AUO) T430QVN03.0 CELL is a 43 inch diagonal a-Si TFT-LCD display panel product, without backlight, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: Reverse I/F, 10 bit, Matte . Based on its features, einklcd recommend that this model be applied to TV Sets etc.Built-in 12 source chips driver IC. According to the information stored in einklcd this model mass production on Q4, 2016, Now this model is in production. We inputted this model's specification on Dec 22 2016 for the first time, and the latest update on Feb 12 2022. If you want to embed T430QVN03.0 CELL CELL in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The T430QVN03.0 CELL production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.





Brand
AUO
Model P/N
T430QVN03.0 CELL
Diagonal Size
43"
Panel Type
a-Si TFT-LCD, CELL , FOB
Resolution
3840(RGB)×2160, UHD 103PPI
Pixel Format
RGB Vertical Stripe
Active Area
941.184(W)×529.416(H) mm
Bezel Opening
-
Outline Dim.
953(H)×543(V) ×1.4(D) mm
Treatment
Antiglare (Haze 2%), Hard coating (3H)
Luminance
0 cd/m²
Contrast Ratio
4000:1 (Typ.) (TM)
View Direction
Symmetry
Response Time
8 (Typ.)(G to G)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
AMVA3, Normally Black, Transmissive
Plate Thickness
0.50+0.50 mm
Transmittance
4.3% (Typ.)(with Polarizer)
Support Color
1.07B 73% NTSC
Light Source
No B/L
Weight
1.50Kgs (Typ.)
Designed For
AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI  1.07B Color 51pin 0
Frame Rate
60Hz
Touch Panel
Without
D-IC Detail
COF Built-in 12 source chips
Interface Type
V-by-One 8 lane , 51 pins Connector
Power Supply
12.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

AUO 43Inch LCD TV open cell model T430QVN03.0 UHD3840(RGB)×2160, UHD 103PPI  1.07B Color 51pin 1
