| Brand Name: | BOE |
| Model Number: | DV550QUM-N10 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
55inch BOE LCD TV Panel DV550QUM-N10 3840*2160pixels 55" LVDS 51pin 80PPI 12.0V
BOE Technology Group Co., Ltd. (hereafter called BOE) DV550QUM-N10 is a 55 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by Einklcd in the following: sRGB, Hight Brightness, WLED Backlight, Life ≥ 50K hours, Reverse I/F, 10 bit, Matte . Based on its features, Panelook recommend that this model be applied to Digital Signage, Outdoor High Brightness etc. According to the information stored in einklcd this model mass production on Q1, 2019, Now this model is in production. We inputted this model's specification on Mar 25 2019 for the first time, and the latest update on Aug 26 2021. If you want to embed DV550QUM-N10 LCM in your future product,Einklcd strongly recommend that you should contact with BOE or it's distributor to learn lateast production and specification detail. The DV550QUM-N10 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
| Brand | BOE | Model | DV550QUM-N10 |
|---|---|---|---|
| Diagonal Size | 55 inch | Type | a-Si TFT-LCD , LCM |
| Pixel Format | 3840(RGB)×2160 [UHD] 80PPI | Configuration | RGB Vertical Stripe |
| Active Area | 1209.6(H)×680.4(V) mm | Outline Dim. | 1232.8(H)×703.6(V) ×32.9(D) mm |
| Bezel Area | - | Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Luminance | 800 cd/m² (Typ.) | Contrast Ratio | 1200:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | ADS, Normally Black, Transmissive |
| Support Color | 1.07B 74% NTSC | Light Source | WLED [18S4P×2CN] , 50K hours , W/O Driver |
| Weight | 15.0Kgs (Typ.) | Designed For | |
| Frame Rate | 60Hz | Touch Panel | Without |
| Interface Type | V-by-One 8 lane , 51 pins Connector | ||
| Power Supply | 12.0V (Typ.) | ||
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C | ||
|
