LG 11.6 Inch 1366×768 Resolution 220CD/M2 Brightness TFT-LCD Display Desktop Monitor Module

Name: LG 11.6 Inch 1366×768 Resolution 220CD/M2 Brightness TFT-LCD Display Desktop Monitor Module
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LP116WH7 SPC2
Price: 30.00 USD
Availability: InStock

Brand Name:	LG
Model Number:	LP116WH7 SPC2
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Brightnerss:

220CD/M2

Connector:

30PIN

Color:

262k

Contrast Ratio:

600:1

Working Life:

15K Hours

Resolution:

1366*768pixels

Voltage Supply:

3.3V

Signal Type:

LCM

Packaging Details:

Industrial packing

Highlight:

220CD/M2 30PIN Desktop Monitor Module

LP116WH7 TFT LCD display panel

Product Description

LG 135PPI Desktop Monitor Module 11.6Inch LP116WH7 SPC2 1366*768

LG 135PPI Desktop Monitor Module 11.6Inch LP116WH7 SPC2 1366*768 220CD/M² 30PIN

The LG Display LP116WH7-SPC2 (Product Code: LGD04DC) is an 11.6-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system and LED driver. This glossy display module features a slim form factor designed for laptop applications and operates within a temperature range of 0~50°C.

Product Specifications

Brand	LG
Display Model	LP116WH7-SPC2 (LGD04DC)
Diagonal Size	11.6 inch
Display Type	a-Si TFT-LCD, LCM
Resolution	1366*768 (WXGA) 135PPI
Active Area	256.125*144 mm
Outline Dimensions	268.35157.354.8 mm
Luminance	220 cd/m² (Typ.)
Contrast Ratio	600:1 (Typ.)
Response Time	35 ms (Typ.)
Viewing Angle	80/80/80/80 (CR≥10)
Operating Mode	IPS, Normally Black, Transmissive
Color Support	262K colors, 49% NTSC
Backlight	WLED, 15K hours lifespan, With LED Driver
Interface	eDP (2 Lanes), HBR1 (2.7G/lane), 30-pin Connector
Power Supply	3.3V (Typ.)
Frame Rate	60Hz (120Hz with Embedded MEMC Circuit)
Touch Panel	Without touch screen
Surface Treatment	Glare (Haze 0%), Hard coating (3H)

Environmental Specifications

Operating Temperature	0 ~ 50°C
Storage Temperature	-20 ~ 60°C

Product Images

Note: This model entered mass production in Q4 2016 and is currently discontinued. Specifications were last updated on January 10, 2022. For integration into future products, please contact LG Display or their distributors for the latest production and specification details.
