Product Details:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Brightnerss: | 250CD/M2 | Connector: | 40PIN |
| Color: | 262k | Contrast Ratio: | 1000:1 |
| Working Life: | 15K Hours | Resolution: | 1366*768pixels |
| Voltage Supply: | 3.3V | Signal Type: | LCM |
| High Light: | NV116WHM-T04 LCD Module,Desktop Monitor Display Panel 1366×768 |
||
BOE 135PPI Desktop Monitor Module 11.6Inch NV116WHM-T04 1366×768 350CD/M2 40PIN
The NV116WHM-T04 (Product Code: BOE0965) is a 11.6 inch diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, With LED Driver , touchscreen On-Cell Touch. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Einklcd in the following: WLED Backlight, With LED Driver, Reverse I/F, Glossy , eDP1.2; Google OS; BIST. Based on its features, einklcd recommend that this model be applied to Laptop etc. According to the information stored in einklcd this model mass production on Q1, 2021, Now this model is in production. We inputted this model's specification on Jan 21 2021 for the first time, and the latest update on Mar 24 2022. If you want to embed NV116WHM-T04 LCM in your future product,einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail. The NV116WHM-T04 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
| Panel Brand |
|---|
| Panel Size |
| Resolution |
| Display Area |
| Outline Size |
| Brightness |
| Viewing Angle |
| Best View on |
| Display Colors |
| Frequency |
| Shape Style |
| BOE |
| 11.6" |
| 1366(RGB)×768, WXGA, 135PPI |
| 256.125(W)×144(H) mm |
| 278(W)×168(H) ×3.2(D) mm |
| 250 cd/m² (Typ.) |
| 85/85/85/85 (Typ.)(CR≥10) |
| Symmetry |
| 262K 50% NTSC |
| 60Hz |
| Slim (PCBA Flat, T≤3.2mm) |
| Panel Model |
| Panel Type |
| Pixel Format |
| Bezel Opening |
| Surface |
| Contrast Ratio |
| Display Mode |
| Response Time |
| Lamp Type |
| Touch Screen |
| Application |
| NV116WHM-T04 (BOE0965) |
| a-Si TFT-LCD , LCM |
| RGB Vertical Stripe |
| - |
| Glare (Haze 0%), Hard coating (3H) |
| 1000:1 (Typ.) (TM) |
| ADS, Normally Black, Transmissive |
| 20 (Typ.)(Tr+Td) |
| 8S3P WLED , 15K hours , With LED Driver |
| On-Cell Touch |
| Signal Interface | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector |
|---|---|
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
