| Brand Name: | auo |
| Model Number: | T320HVN05.6 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
AUO 31.5" LCD Touch Screen Monitor T320HVN05.6 51Pin 1920*1080 For Desktop Monitor TV Panel
| Panel Brand | AUO | Panel Model | T320HVN05.6 CELL |
|---|---|---|---|
| Panel Size | 31.5" | Panel Type | a-Si TFT-LCD , CELL |
| Resolution | 1920(RGB)×1080 , FHD | Pixel Format | RGB Vertical Stripe |
| Display Area | 698.4(W)×392.85(H) mm | Bezel Opening | - |
| Outline Size | 708.4(W)×405.4(H) ×1.4(D) mm | Surface | Antiglare (Haze 2%), Hard coating (3H) |
| Brightness | 0 cd/m² | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | AMVA3, Normally Black, Transmissive |
| Best View on | Symmetry | Response Time | 6.5 (Typ.)(G to G) |
| Glass Depth | 0.50+0.50 mm | Transmissivity | 6.5% (Typ.)(with Polarizer) |
| Display Colors | 16.7M | Lamp Type | No B/L |
| Frequency | 60Hz | Touch Screen | Without |
| Panel Weight | 875g (Typ.) | Application |
|
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins , Connector | ||
| Input Voltage | 12.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C | ||
AU Optronics Corp. (hereafter called AUO) T320HVN05.6 CELL is a 32.0 inch diagonal a-Si TFT-LCD display panel product, without backlight, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: Reverse I/F, Matte . Based on its features, einklcd recommend that this model be applied to TV Sets etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production. We inputted this model's specification on Oct 30 2014 for the first time, and the latest update on Jul 29 2019. If you want to embed T320HVN05.6 CELL CELL in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The T320HVN05.6 CELL production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
All this lcd product are brand new with original package!
|
|
| Brand Name: | auo |
| Model Number: | T320HVN05.6 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
AUO 31.5" LCD Touch Screen Monitor T320HVN05.6 51Pin 1920*1080 For Desktop Monitor TV Panel
| Panel Brand | AUO | Panel Model | T320HVN05.6 CELL |
|---|---|---|---|
| Panel Size | 31.5" | Panel Type | a-Si TFT-LCD , CELL |
| Resolution | 1920(RGB)×1080 , FHD | Pixel Format | RGB Vertical Stripe |
| Display Area | 698.4(W)×392.85(H) mm | Bezel Opening | - |
| Outline Size | 708.4(W)×405.4(H) ×1.4(D) mm | Surface | Antiglare (Haze 2%), Hard coating (3H) |
| Brightness | 0 cd/m² | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | AMVA3, Normally Black, Transmissive |
| Best View on | Symmetry | Response Time | 6.5 (Typ.)(G to G) |
| Glass Depth | 0.50+0.50 mm | Transmissivity | 6.5% (Typ.)(with Polarizer) |
| Display Colors | 16.7M | Lamp Type | No B/L |
| Frequency | 60Hz | Touch Screen | Without |
| Panel Weight | 875g (Typ.) | Application |
|
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins , Connector | ||
| Input Voltage | 12.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C | ||
AU Optronics Corp. (hereafter called AUO) T320HVN05.6 CELL is a 32.0 inch diagonal a-Si TFT-LCD display panel product, without backlight, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: Reverse I/F, Matte . Based on its features, einklcd recommend that this model be applied to TV Sets etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production. We inputted this model's specification on Oct 30 2014 for the first time, and the latest update on Jul 29 2019. If you want to embed T320HVN05.6 CELL CELL in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The T320HVN05.6 CELL production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
All this lcd product are brand new with original package!
