Product Details:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Resolution: | 1366*768 | Style: | 30PIN IPS |
| Brightness: | 400 CD/M2 | Color: | 16.7m |
| Contrast Ratio: | 1200 :1 | Working Life: | 50k Hours Without Driver |
| High Light: | flat screen tv panel,lcd tv display panel |
||
| Manufacturer | LG Display | Model Name | LC320DXY-SHAA |
|---|---|---|---|
| Screen Size | 31.5 inch | Screen Type | CELL , a-Si TFT-LCD |
| Pixel Number | 1366(RGB)×768 (WXGA) | Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 697.685 × 392.256 (H×V) | Outline(mm) | 715 × 411 × 1.3 (H×V×D) |
| Bezel Area(mm) | - | Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Luminance | 0 cd/m² | Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Response | 7 (Typ.)(G to G) ms |
| Good View at | Symmetry | Work Mode | IPS, Normally Black, Transmissive |
| Glass Thickness | - | Transmissivity | 6.45% (Typ.)(with Polarizer) |
| Color Depth | 16.7M | Backlight | No B/L |
| Mass | 0.86/0.91Kgs (Typ./Max.) | Used for |
|
| Refresh Rate | 60Hz | Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , Connector , 30 pins | ||
| Voltage Supply | 12.0V (Typ.) | ||
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C | ||
LC320DXY-SHAA (Alias: LC320DXY (SH)(AA)) is a 31.5" diagonal a-Si TFT-LCD display panel product from LG Display Co., Ltd. (hereafter called LG Display), without backlight, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: Antiglare Surface, Wide Viewing Angle, Landscape type, Wide Aspect Ratio . Based on its features,einklcd recommend that this model be applied to TV Sets etc. Now this model is in production. We inputted this model's specification on May 20 2019 for the first time. If you want to embed the CELL in your future product, einklcdstrongly recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail of LC320DXY-SHAA. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
All Origianl product will be send to customer after full test one by one.
