LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD

Customer Reviews
We visited their factory many times.Their workshop is very big and e ink display module are really great!

—— Chris

Our company have placed orders to Ridafone many times.They develop and produce all e ink LCD display items in good quality.

—— Picado Freddy

I'm Online Chat Now

LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD

LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD
LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD

Large Image :  LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD

Product Details:
Place of Origin: China
Brand Name: LG
Certification: Rohs,CE,FCC
Model Number: LD320EUN-SEM1
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week

LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD

Description
Quality: Brand New Original Package: Original Industrial Packing
Resolution: 1920*1080 Style: 51PIN IPS
Brightness: 400 CD/M2 Color: 16.7m
Contrast Ratio: 1300 :1 Working Life: 50k Hours Without Driver
High Light:

flat screen tv panel

,

lcd tv display panel

  • Panel Brand
    Panel Size
    Resolution
    Display Area
    Outline Size
    Brightness
    Viewing Angle
    Best View on
    Display Colors
    Frequency
    Weight
    LG Display
    31.5"
    1920(RGB)×1080 , FHD
    698.4(W)×392.85(H) mm
    727.4(W)×429(H) mm
    400 cd/m² (Typ.)
    89/89/89/89 (Min.)(CR≥10)
    Symmetry
    16.7M 68% (CIE1931)
    60Hz
    5.40/5.70Kgs (Typ./Max.)
    Panel Model
    Panel Type
    Pixel Format
    Bezel Opening
    Surface
    Contrast Ratio
    Display Mode
    Response Time
    Lamp Type
    Touch Screen
    Application
    LD320EUN-SEM1
    a-Si TFT-LCD , LCM
    RGB Vertical Stripe
    705.6(W)×400.1(H) mm
    Antiglare (Haze 1%), Hard coating (3H)
    1300:1 (Typ.) (TM)
    S-IPS, Normally Black, Transmissive
    22 (G to G)
    WLED , 50K hours , With LED Driver
    Without
    Signal Interface LVDS (2 ch, 8-bit) , 51 pins , Connector
    Input Voltage 12.0V (Typ.)
    Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C



    LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD 0LD320EUN-SEM1 LCD TV Panel Display Screen 400CD/M2 Brightness 1920*1080 Pixels HD 1



   All Origianl product will be send to customer after full test one by one.

  • Spec details can be send to you via email,please contact us.
