17 Inch PC LCD Module with 1280x1024 Pixels and 16.7M Color TFT-LCD Display Panel

Brand Name:	auo
Model Number:	DV430FHM-NN0
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

400ccd/m2

Resolution:

1920*1080pixels

Contrast Ratio:

1200:1

Color:

16.7M

Working Life:

30k Hours

Connector:

51P

Touch Panel:

Without

Packaging Details:

Industrial packing

Highlight:

lcd display panel

lcd digital display

Product Description

1280 * 1024 Pixels PC LCD Module 17 Inch Size M170ETN01.1 250CCD/M2 30 Pin 16.7M Color

AUO LCD display module featuring a 17-inch screen monitor model M170ETN01.1 with 1280*1024 pixels resolution, 250CCD/M2 brightness, 30-pin interface, and 16.7 million color support.

Product Specifications

Manufacturer	AUO
Model Name	M170ETN01.1
Screen Size	17.0 inch
Screen Type	LCM, a-Si TFT-LCD
Pixel Number	1280(RGB) * 1024 (SXGA)
Arrangement	RGB Vertical Stripe
Active Area	337.92 * 270.336 mm (H*V)
Outline Dimensions	358.5 * 296.5 * 10.8 mm (HVD)
Bezel Area	341.72 * 274.14 mm (H*V)
Surface Treatment	Antiglare, Hard coating (3H)
Luminance	250 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	85/85/80/80 (Typical, CR ≥10)
Response Time	3.8/1.2 ms (Typical, Tr/Td)
Optimal Viewing	6 o'clock
Work Mode	TN, Normally White, Transmissive
Color Depth	16.7M 72% (CIE1931)
Backlight	9S4P WLED, 30K hours, No Driver
Mass	1.27 kg (Typical)
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	LVDS (2 ch, 8-bit), Connector, 30 pins
Voltage Supply	5.0V (Typical)
Temperature Ratings	Storage: -20°C to 60°C, Operating: 0°C to 50°C
