Glass Led 12.0V Big Computer Screen , 51 Pins LVDS 60Hz Lcd Touch Screen

Brand Name:	BOE
Model Number:	DV550FHM-NN0
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Led

Color:

Black Or Silver,16.7M Color For Display

Model:

WLED,LCD

Style:

Wide Screen High Resolution 1920*1080pixels

Supply Ability:

3000pcs per week

Highlight:

large flat screen monitor

big computer screen

Product Description

Brand

BOE

Model

DV550FHM-NN0

Diagonal Size

55 inch

Type

a-Si TFT-LCD, LCM

Pixel Format

1920(RGB)×1080 [FHD]

Configuration

RGB Vertical Stripe

Active Area

1209.6(H)×680.4(V) mm

Outline Dim.

1230.4(H)×706.8(V) ×40.2(D) mm

Bezel Area

-

Treatment

Antiglare (Haze 1%), Hard coating (3H)

Luminance

350 cd/m² (Typ.)

Contrast Ratio

1200:1 (Typ.) (TM)

View Direction

Symmetry

Response Time

8 (Typ.)(G to G)

Viewing Angle

89/89/89/89 (Typ.)(CR≥10)

Operating Mode

ADS, Normally Black, Transmissive

Support Color

16.7M 72% (CIE1931)

Light Source

WLED , 30K hours , With LED Driver

Weight

13.3Kgs (Typ.)

Designed For

Frame Rate

60Hz

Touch Panel

Without

Interface Type

51 pins LVDS (2 ch, 8-bit) , Connector

Power Supply

12.0V (Typ.)

Environment

Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

All our LCD LED screen monitor module panel products will be full test one by one before sending .
