| Brand Name: | BOE |
| Model Number: | DV490FHM-NN0 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
BOE WLED TV wide Screen model 49" DV490FHM-NN0 LCD TV screen panel 16.7M colors Brand new 1920*1080ixels lcd TV panel
| Panel Brand |
|---|
| Panel Size |
| Resolution |
| Display Area |
| Outline Size |
| Brightness |
| Viewing Angle |
| Best View on |
| Display Colors |
| Frequency |
| Videowall Seam |
| BOE |
| 49 inch |
| 1920(RGB)×1080 , FHD |
| 1073.78(W)×604(H) mm |
| 1090.4(W)×621.3(H) ×27.36(D) mm |
| 380 cd/m² (Typ.) |
| 89/89/89/89 (Typ.)(CR≥10) |
| Symmetry |
| 16.7M 68% (CIE1931) |
| 60Hz |
| 3.9 mm (active to active seam) |
| Panel Model |
| Panel Type |
| Pixel Format |
| Bezel Opening |
| Surface |
| Contrast Ratio |
| Display Mode |
| Response Time |
| Lamp Type |
| Touch Screen |
| Application |
| DV490FHM-NN0 |
| a-Si TFT-LCD , LCM |
| RGB Vertical Stripe |
| 1078.6(W)×609.5(H) mm |
| Antiglare (Haze 1%) |
| 1200:1 (Typ.) (TM) |
| ADS, Normally Black, Transmissive |
| 8 (Typ.)(Tr+Td) |
| WLED , 15K hours , With LED Driver |
| Without |
|
|
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins , Connector |
|---|---|
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
