| Brand Name: | CHIMEI innolux |
| Model Number: | V500HK1-LS6 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Manufacturer | Chimei Innolux | Model Name | V500HK1-LS6 Rev.C7 |
|---|---|---|---|
| Screen Size | 50 inch | Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) | Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 1095.84 × 616.41 (H×V) | Outline(mm) | 1115.04 × 638.41 × 28.6 (H×V×D) |
| Bezel Area(mm) | 1103.04 × 622.41 (H×V) | Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Luminance | 400 cd/m² (Typ.) | Contrast Ratio | 5000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥20) | Response | 6.5 (Typ.)(G to G) ms |
| Good View at | Symmetry | Work Mode | Super MVA, Normally Black, Transmissive |
| Color Depth | 16.7M 72% (CIE1931) | Backlight | WLED , 30K hours , With LED Driver |
| Mass | 12.2±0.6Kgs | Used for |
|
| Refresh Rate | 120Hz (60Hz Input) | Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , Connector , 61 pins | ||
| Voltage Supply | 12.0V (Typ.) | ||
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C | ||
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
